Main Menu Options; Auto Run Mode; Built-In Programs; Slave Mode - SHOWTEC Data Flash Strobe V1 Manual

Data Flash Strobe

Main Menu Options

1. Auto Run Mode

With this menu you can start Auto Run mode.
01) Press the MODE button and then the UP/DOWN buttons, until the display shows
02) The Data Flash Strobe will now run all the built-in programs in a sequence.

2. Built-in Programs

With this menu you can you can set the built-in programs.
01) Press the MODE button and then the UP/DOWN buttons, until the display shows
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to scroll through the 25 built-in programs. The adjustment range is
between
04) Once you have selected one of the programs
open the program.
05) Press the SETUP button several times to toggle between strobe frequency and program speed
settings.
06) Press the UP/DOWN buttons to change the values.

3. Slave Mode

With this menu you can set the device as a slave device.
01) Press the MODE button and then the UP/DOWN buttons, until the display shows
02) If the device has not been set to slave, it is automatically classified as a master device. All slave
devices will follow the master movement. If the device has been set to slave, it will react the same as
its master device.
Ordercode: 40296
1. Auto run
2. Built in programs
3. Slave mode
4. DMX addressing
5. Sound-controlled mode
6. Dimmer options
7. Settings
8. Info
Program speed, from 001-100
Strobe frequency, from 00-99
14
.
.
, press the SETUP button to
.
