Dmx Channels; Channels - SHOWTEC Data Flash Strobe V1 Manual

Data Flash Strobe

DMX Channels

12 channels

Channel 1 – Dimmer intensity
0-255 Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Section 1 (
0-255 Gradual adjustment section 1, from dark to brightest 0-100%
Channel 3 – Section 2 (
0-255 Gradual adjustment section 2, from dark to brightest 0-100%
Channel 4 – Section 3 (
0-255 Gradual adjustment section 3, from dark to brightest 0-100%
Channel 5 – Section 4 (
0-255 Gradual adjustment section 4, from dark to brightest 0-100%
Channel 6 – Section 5 (
0-255 Gradual adjustment section 5, from dark to brightest 0-100%
Channel 7 – Section 6 (
0-255 Gradual adjustment section 6, from dark to brightest 0-100%
Channel 8 – Section 7 (
0-255 Gradual adjustment section 7, from dark to brightest 0-100%
Channel 9 – Section 8 (
0-255 Gradual adjustment section 8, from dark to brightest 0-100%
Channel 10 – Built-in Programs (
1-9 Program 01
10-19 Program 02
20-29 Program 03
30-39 Program 04
40-49 Program 05
50-59 Program 06
60-69 Program 07
70-79 Program 08
80-89 Program 09
90-99 Program 10
100-109 Program 11
110-119 Program 12
120-129 Program 13
130-139 Program 14
140-149 Program 15
150-159 Program 16
160-169 Program 17
170-179 Program 18
180-189 Program 19
190-199 Program 20
Ordercode: 40296
Dimmer must be open
Dimmer must be open
Dimmer must be open
Dimmer must be open
Dimmer must be open
Dimmer must be open
Dimmer must be open
Dimmer must be open
Dimmer and dimmer speed must be open
)
)
)
)
)
)
)
)
18
)
