48 DCx camera
2.39
SetFlashStrobe
Description:
SetFlashStrobe
with the Mode parameter here. In addition, the active level (high or low) can be set. By
default, the strobe is high active. The constants
IS_SET_FLASH_LOW
output only works in triggered mode.
Parameters:
Camera Handle In/Out
Mode
IS_SET_FLASH_OFF (0)
IS_SET_FLASH_ON (1)
IS_SET_FLASH_HI_ACTIVE (2)
IS_SET_FLASH_HIGH (3)
IS_SET_FLASH_LOW (4)
IS_GET_FLASHSTROBE_MODE (32768)
Mode
error in/out
VI:
Related functions
SetFlashDelay
GetGlobalFlashDelays
SetExternalTrigger
All manuals and user guides at all-guidesbox.com
activates the flash/strobe. Triggering can be activated or deactivated
allow the strobe output to be used as a digital output. The flash
Handle on camera
Switches off the strobe output
Sets the strobe output to low active
Sets the strobe output to high active
Sets strobe output to HIGH
Sets strobe output to LOW
Returns the current mode
Returns the setting queried with Get
Error code
47
24
46
and
IS_SET_FLASH_HIGH
© 2010 Thorlabs
