40 DCx camera
2.31
SetBlCompensation
Description:
SetBlCompensation
quality. Depending on when the compensation is changed, this setting may not take
effect until capturing the next image.
Parameters:
Camera Handle In/Out
Mode
IS_BL_COMPENSATION_DISABLE (0)
IS_BL_COMPENSATION_ENABLE (1)
IS_GET_BL_COMPENSATION (32768)
IS_GET_BL_OFFSET (32769)
IS_GET_BL_DEFAULT_MODE (32770)
IS_GET_BL_DEFAULT_OFFSET (32771)
IS_GET_BL_SUPPORTED_MODE (32772)
IS_IGNORE_PARAMETER (-1)
offset
Value
error in/out
VI:
All manuals and user guides at all-guidesbox.com
activates black level compensation, which may improve image
Handle on camera
Deactivates compensation
Activates black level compensation using the set
offset value
Returns the current mode
Returns the current offset
Returns the standard mode
Returns the standard offset
Returns the supported modes. Possible values:
IS_BL_COMPENSATION_ENABLE
The sensor
compensation
IS_BL_COMPENSATION_OFFSET
With the sensor used, the offset of the black level
compensation
can be set
Mode parameter is ignored
Contains the offset used for compensation. Possible
values range from 0 to 255.
Contains the return value when an
is passed
Error code
(1):
used supports black
(32):
parameter
IS_GET
© 2010 Thorlabs
level
