Appendix A: Specification
Off Centre Function
Display Windows
Wakes
Target Expansion
Timed TX

Chartplotter Features

Cartography
Display Windows
Chart Scaling
Presentation Modes
Waypoints
Waypoint Transfer
Routes
Track History
Alarms
Navigation Information
Variation Source
Chart/Radar Synchronisation
66% of radius (except maximum range)
Radar, Chart, CDI, BDI and Navdata
Short, medium, long, off
Operator selectable (0.5 nm to 3 nm ranges only)
Rotation periods: 10, 20 or 30 scans
Repetition periods: 3, 5, 10 or 15 minutes
C-MAP® NT micro cartridges available from C-MAP®
Chart of the world built in
Chart, Radar, Data Log, BDI, CDI, Navdata
1/64 nm (if cartographic data is available) to 4000 nm
North up (selectable True or Magnetic) Head up or Course up
1000 waypoints entered via cursor, lat/lon, range
and bearing from present position or at vessels position.
16 character name can be assigned
HSB, current route via Seatalk, NMEA
A route plan may contain up to 50 waypoints. Up to
20 routes can be stored in the units internal memory
10 tracks with up to 500 points in each can be stored in the
units internal memory
Programmable arrival, cross track error, anchor drift,
position fix/data loss warning, countdown timer and alarm
clock
Own ships position in Lat/Lon, XTE, TTG and SOG/COG
selectable. Mileage scale ruler. Bearing and distance to
waypoint. Bearing and distance to cursor, SeaTalk data
(see 'interfacing' section)
Auto (SeaTalk/NMEA/Internal algorithm) or Manual
User selectable in split screen mode provided radar/chart
data available
179
