ROBE UNIT
Feature Robe Assembly Guide
(F) x16
(L) x10
(K) x6
(P) x6
(W) x12
(H) x12
Wooden Dowel
15mm Screw
30mm Screw
45mm Screw
Cam Dowel
Cam Lock
(LL) x5
x2
x28
15mm Cover Cap
Anti Tipping
Loose Shelf Peg
Bracket
Robe
Legs
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1
Page 4
