- Page 1 FRONTALS INFINITY INFINITY Attachment Guide Standard Drawer Gallery Rail Drawer For Internal Use:50-WKIN00142_INFINITY_DRAWER_ATTACHMENT_GUIDE_Rev1...
- Page 2 FRONTALS STANDARD DRAWER INFINITY Attachment Guide Step 1. Secure drawer side fixing clips using 2 x 13/16” screws per clip using the spiked positions. Drawer side fixing clip Standard 4“ 4“ Drawer 2 3/14“ 2 3/4“ Fixing clip 1 1/2“ 1 1/2“...
- Page 3 FRONTALS DEEP DRAWER, GALLERY SIDES DEEP DRAWER INFINITY GALLERY SIDES Attachment Guide Fixing clip Step 1. Secure gallery head fixing clips using 1 x 9/16“ screw and secure drawer side fixing clips using 2 x 13/16“ screws located with the spiked positions. Drawer front Gallery head...
