ROBE UNIT
Feature Robe Assembly Guide
1 x Back Panel
2 x End Panels
1 x Bottom
1 x Top
2 x Rails
Loose Shelf
(A)
(B)
Fixed Shelf
Fixed Shelf
(D)
Pack
(Cb)
(Ct)
Throughout this instruction the
full depth 7 shelf feature robe
will be used for reference only
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1
Page 3
