Danfoss PLUS+1 Compliant User Manual page 34

User Manual
Ouster LiDAR
Inputs, Outputs, and Parameters
34 | © Danfoss | March 2023
Item Type
O_PtCld S8
Eth_Config BUS
Range Description [Unit]
-1-99 Reports the ID of the data locker where the block
writes LiDAR scan data. Use this output with a
compatible Autonomous Control Library 2.6 or
later function block.
—— Transmits data for connecting an Ouster LiDAR
hardware directly into the Ethernet port of the
controller. To use this output, connect it directly to
the Ethernet bus in the outputs template.
Do not use this with a network switch or with
multiple devices connected to one controller.
AQ404281942428en-000103
