Pandora Mini V4 is a car service-security system, built for cars with on-
board voltage of 12V.
It is a complex engineering product, which includes unique and modern
software and hardware solutions. When building the Pandora Mini V4 we were
using the most up-to-date electronics from world's best manufacturers. The
device is built using high-precision mounting and control machinery, thus we
guarantee highest possible quality, reliability and stable technical characteris-
tics for the whole operation period.
Elegant and advanced technical design and unique ergonomic interaction
algorithms that are used in the Pandora Mini V4 allow enhancing your car with
fantastic set of intuitive and useful functions.
WARNING! I
INstAllING the system
INstAll the
ANd
competeNt INstAllAtIoN
so If A feAtuRe fAIls to pRoduce expected Result
IN ImpRopeR INstAllAtIoN
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40° to +80° C range.
www.pandorainfo.com
Our web site:
Customer support:
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
Pandora would like to thank you for choosing our
t Is stRoNGly AdvIsed to hAve pRofessIoNAl cAR mechANIc
. A
p
m
ANdoRA
p
s
ANdoRA
pecIAlIst softWARe
. o
.
support@pandorainfo.com
service-security system
Ny cAR electRoNIcs INstAlleR should be Able to
v4
INI
usING INstAllAtIoN scheme IN thIs mANuAl
. m
ost feAtuRes ARe hIGhly depeNdeNt oN
uR systems ARe thoRouGhly tested foR quAlIty
,
most lIkely the pRoblem Is
,
Advertisement
Table of Contents
Related Manuals for Pandora Mini V4
Summary of Contents for Pandora Mini V4
- Page 1 Elegant and advanced technical design and unique ergonomic interaction algorithms that are used in the Pandora Mini V4 allow enhancing your car with fantastic set of intuitive and useful functions. WARNING! I...
-
Page 2: Table Of Contents
Warranty obligations Arming Installation certificate Disarming Acceptance certificate Warranty card Service (VALET) mode Control over the system in case of emergency Emergency disarming using the VALET button Emergency control of the anti-theft functions PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 3: System Set
Built-in sensors – These sensors are integrated in the base unit. The sensors perform control and protection of the vehicle. Additional connections are not required Additional sensor (*optional) – External additional sensors are connected to the base unit. PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 4: Arming Mode
The immobilizer code can consist max of 4 digits from 1 to 9. • Turn on the ignition to disable engine blocking or service mode, turning • • Closing windows • •* Engine pre-heaters PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 5: Immobilizer Mode
The tag also has a LED indicator ”SEND”. when the ignition is on, the system requests a response from a radio tag using a unique algorithm. After a door was opened while the ignition is on, if the PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 6: Functions Of The Button
(system is disarmed) - hold for 6 seconds Pair a tag with the base unit Battery CR 2032 - hold for 10 seconds Firmware update fig.2 (-) side SEND – three ashes PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 7: Updating Firmware Of The Tag
• Press and hold the button on the radio tag until the 10th flash of the SEND The mobile application Pandora Connect for Android and iOS devices is a ser- indicator, then release the button. vice application to control and manage the system state via the Bluetooth con- •... -
Page 8: Using The Application
AddItIoNAl settINGs to ActIvAte thIs fuNctIoN Doors Shock sensor Front hood Tilt sensor Trunk Motion sensor Ignition Additional sensor Brake pedal On-board voltage Engine is running Fuel level Interior/engine temperature Outside temperature PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 9: Control Over The System
HandsFree mode Move with a remote tag (or a paired mobile phone) away from your vehicle Note! A ddItIoNAl settINGs ARe RequIRed foR usING the ANds Ree mode WIth A mobIle phoNe PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 10: Disarming
To disarm the system, shortly press the “Unlock” button on an original re- mote control or use a sensor/button on a door handle (for cars with an intel- ligent access system). Note! A ddItIoNAl settINGs oR coNNectIoNs ARe RequIRed foR thIs mode PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 11: Service (Valet) Mode
Switch on/ off the service mode using a phone and the Pandora Connect application CONTROL OVER THE SYSTEM IN CASE OF EMERGENCY • To switch on the Service mode, open the mobile application. When the sys-... -
Page 12: Emergency Control Of The Anti-Theft Functions
Enter the ‘Secret PIN-code’ that is written on the Owner’s personal card. The system will confirm deactivating with two sound signals of the siren, a long PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... - Page 13 The security system does not require IT IS FORBIDEN to bypass original fuses system, select a car model in the Pandora Specialist regular maintenance. In case of malfunction it of a security system in the installation process. application (CAN-bus protocol).
-
Page 14: System Installation
Wire №9 (Blue) CH3 — LED/VALET. This wire connects to the black wire of the external VALET button. Wire №10 (Brown-white) 200mA (-) CH3/INP3 — Factory setting is “Front hood”. This wire connects to appropriate wire that becomes grounded when the front hood opens. PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 15: System Configuration And Programming
Wire №11 (Orange-black) CAN1-L — wire of digital bus CAN1-Low. It con- nects to an appropriate CAN-Low wire of a car. System settings and parameters can be configured using the Pandora Wire №12 (Yellow-black) 200mA (-) CH5/CAN2-L — wire of digital bus CAN2- Specialist application. -
Page 16: Pandora Specialist
1 second. The system will confirm correct input with red LED flashes and short sound signals of the siren/beeper and proceed • Install the Pandora Specialist to a PC with Windows (64-bit only) or a smartphone;... -
Page 17: Programming Levels Table
Р №10.6 – Pairing an engine compartment module P RHM-03BT/PS-331BT/PS-332BT №10.7 – Pairing an additional device DI-04 P or BT-01 №10.8 – Pairing a telemetry module Pandora Eye P Pro / NAV-X PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... - Page 18 • Enter the first digit of the code using the VALET button. Press the button a return to the programming mode. number of times, equals to the first digit. Pauses between presses should not exceed 1 second, every pressing will confirm with an orange LED indica- PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL...
- Page 19 The system will enter the programming level №0. light red after entering. Press and hold (H) the VALET button for 6 seconds. Open the Pandora Specialist, go to “Search device” screen and select the device and then select one of the update options: An example of pairing door sensor DMS-100 BT: •...
- Page 20 - Incorrect confirmation is indicated with a long red flash of the LED indica- tor, the system will cancel the input and return to the programming mode. PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL...
-
Page 21: Beeper Sound Signals
1 sec. interval. The number of the signals equals to the number of recorded radio tags. After a pause of 2 Blocking warning Fast sound signals seconds the system signal will indicate registered mobile device. PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 22: Additional Devices
The system controls the relay via a normally closed relay, “opening/closing hood lock” radio channel. outputs, siren output, digital LIN output for an engine preheater, hood switch input. PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 23: System Module Layout
Telemetry modules Pandora Eye Pro and NAV-X System modules layout Additional devices designed to extend the system function with telemetric and service functions by GSM Ask an installer to mark system’s modules on the picture provided. This infor- and the Internet connection: mation can be important for diagnostics in case system malfunctions. -
Page 24: Warranty Obligations
Date “____“___________________20___y Maintenances and repairs of the system with expired warranty period are car- ried out at the expense of the user on a separate contract between the user and the installer/service center. PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 25: Acceptance Certificate
EMC 2004/108/EC and R&TTE Directive 1999/5/EC. Serial number Date of production Responsible person’s signature (stamp) Packager Signature (personal stamp) Warranty card Model Pandora Mini V4 Serial number Date of purchase «____» ______________________ 20____year Seller’s (installer’s) stamp Seller’s signature PANDORA MINI V4 CAR SERVICE-SECURITY SYSTEM...
