Pandora DXL 1840L is a premium car service-security system, built for cars with on-board voltage
of 12V. It is a complex engineering solution which includes car security system, telemetry, remote and
automatic engine start and various service options, all controlled from your OEM key remote, smart-
phone or online service.
When building Pandora DXL 1840L we were using the most up-to-date electronics from world's
best manufacturers. The device is built using high-precision mounting and control machinery, thus we
guarantee highest possible quality, reliability and stable technical characteristics for the whole opera-
tion period.
Pandora DXL 1840L has a cryptographically strong authorization code with unique dialog algo-
rithm and individual 128 bit encryption key on every device. We guarantee 100% protection form elec-
tronic hacking for the whole operation period.
The system is built for your convenience: it's ergonomic, reliable, has the highest security and service
characteristics, 3 years unconditional warranty and free service and support on the territory of Russain Fed-
eration and nearest states. We are happy to provide any support we can – feel free to use our online support.
WARNING! IT IS STRONGLY ADVISED TO HAVE PROFESSIONAL CAR MECHANIC
INSTALLING THE SYSTEM. ANY CAR ELECTRONICS INSTALLER SHOULD BE ABLE
TO INSTALL PANDORA DXL 1840L USING INSTALLATION SCHEME IN THIS MANU-
AL AND ALARMSTUDIO SOFTWARE. MOST FEATURES ARE HIGHLY DEPENDENT
ON COMPETENT INSTALLATION. OUR SYSTEMS ARE THOROUGHLY TESTED FOR
QUALITY, SO IF A FEATURE FAILS TO PRODUCE EXPECTED RESULTS, MOST LIKELY
THE PROBLEM IS IN IMPROPER INSTALLATION
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40 to +80° C range. All system components must be installed only in a car interior.
.
IMPORTANT! Note that this manual describes remote and manual functions for the most
part. Functionality of the system is vast and would require a book-sized manual to fully describe.
Instead we use handy software named AlarmStudio that functions as both programming tool and
an extended installation & functionality manual. It requires Windows and can be downloaded at
pandorainfo.com
www.pandorainfo.com
Our web site:
Customer support:
Pandora would like to thank you for choosing our
support@pandorainfo.com
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
DXL 1840L service and security system
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pandora DXL 1840L
Summary of Contents for Pandora DXL 1840L
- Page 1 Pandora would like to thank you for choosing our DXL 1840L service and security system Pandora DXL 1840L is a premium car service-security system, built for cars with on-board voltage of 12V. It is a complex engineering solution which includes car security system, telemetry, remote and automatic engine start and various service options, all controlled from your OEM key remote, smart- phone or online service.
-
Page 2: Table Of Contents
Online service and mobile application Installation and configuration of the system Installation requirements Wiring diagram Wiring description Programming the systems Preparing to program the system using a computer Updating firmware Programming using VALET button Additional devices PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 3: Car Security Zones
• Built-in button to control over security modes. parameters without notification. • Built-in integral accelerometer. Car security zones Pandora DXL 1840L service-security system guards following independent zones: • car doors perimeter • front hood triggers * - Availability of this function depends on car make and model... -
Page 4: Control Over The System
This mode is enabled by default. Use a phone to disable this mode (see ‘Control over system via a phone’ To arm/disarm the system, RF tag should be in the Bluetooth coverage section). When switching on the ignition, the base unit of Pandora security system performs a search area. The system produces a protected (AES-128 encryption) interac- for immobilizer tags in radio zone. -
Page 5: Anti-Hi-Jack-2 Mode
To enable the maintenance mode, disarm the system, switch on the ignition, the radio tag should This mode is disabled by default. Use Pandora AlarmStudio application to enable this mode. Anti-Hi- be in the coverage zone (if the immobilizer/AntiHijack function is activated), enter the ‘Immobilizer PIN- Jack-2 mode helps to prevent aggressive seizure of the car using delayed engine blocking on radio tag code’... -
Page 6: Control Over The System In Case Of Emergency
LED indicator flash. A Pause for more than 1 second and a red LED indicator flash confirm the input of the first digit. Then you can enter the next digit. PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 7: Enabling/Disabling Immobilizer Radio Tag
+XXXXXXXXXXX,123*,297* where ‘+XXXXXXXXXXX’ – the system phone number, ‘ , ’ - pause is a feature of the phone (can be displayed as the ‘P’ , see the instructions of the phone), ‘123*’ - remote engine start DTMF command, PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL... - Page 8 1. Call the system number. Wait for answer. Arming/disarming 2. Dial 500*. Pandora system has function of promptly disabling automatic engine start. 3. The system will confirm: ‘Current coordinate sent via text message’ and will send text message 1. Call the system number. Wait for answer.
-
Page 9: Changing Settings Via Phone
1. VIA A PHONE, USING CORE SETTINGS MENU. Voice calls when radio relay connection is lost Settings of the warning level of the 2. VIA A COMPUTER AND PANDORA ALARMSTUDIO SOFTWARE shock sensor sensitivity Voice calls when on-board voltage Sensor... -
Page 10: Online Service And Mobile Application
Online service and mobile application Control via radio channel Mobile applications Pandora Online and Pandora Pro can control the system, receive status infor- Warning! For the correct operation of the GSM mation and open advanced settings without Internet connection when the phone is in the Bluetooth pandora-on.com... - Page 11 Arming 09:00 165 Fleet St, London EC4A 2DY, UK 09:00 Automatic Hands Free Tracking Voice calls engine start Automatic Siren Text switching on mode receiver connection messages of the engine preheater PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL...
-
Page 12: Installation And Configuration Of The System
Motion Left front Left rear Warning zone sensor door door of the supplementary sensor Enter system Loss Trunk programming of GSM mode connection PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL... - Page 13 For remote engine start IMMO-KEY2 OUT Black 200 mA (–) IMMO-KEY1 IN Green CH9 - Bypass * When CH6 is assigned as “NC Blocking” White (–) 200 mA (–) Blue IMMO-KEY1 OUT (–) CH6 - NO Blocking Green Green/Black 200 mA (–) Yellow (–) CH10 - Starter...
-
Page 14: Wiring Description
This input is multi- purpose, it can operate in accordance with selected logic. • Wire«4» (Green) (CH9)— Factory setting is ‘Bypass’ . Output activates during remote or automatic PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 15: Programming The Systems
Pauses between presses should not exceed 1 second. Each pressing will be confirmed with It is required to create an account in AlarmStudio to use Pandora CLONE for remote engine start (you an orange LED indicator flash. A pause for more than 1 second and a red LED indicator flash confirm the can register without a connection to a system). -
Page 16: Updating Firmware
To finish the recording of radio tags into the system, VALET button should be pressed once again, Level 15 Emergency disabling of immobilizer radio tag the series of red and green flashes of status LED indicator will confirm the saving. PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL... - Page 17 LED indicator will confirm the saving, switch on the ignition reboot after saving the idle speed. to automatically save the settings and exit the programming mode. PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL...
- Page 18 If you determine buttons via digital protocol select one or more buttons (up to four) for entering the secret code of the immobilizer. To do this press the selected button, LED indicator will confirm input PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL...
- Page 19 VALET button 23 times for the door sensor №1 or 24 times for the door sensor №2. LED indicator LED indicator will light green after entering the level. Open ‘Pandora Online’ mobile application, go will light green and the system will enter the recording of a door sensor mode. Insert the battery into to ‘Bluetooth Control’...
-
Page 20: Additional Devices
GPS/GLONASS -receiver NAV-035 BT movement. Pandora NAV-035 BT is a high-sensitivity GPS/GLONASS receiver that designed to be used with Pandora service-security systems. The Antenna 2,4 GHz receiver operates on 2,4 GHz wireless interface. The receiver can be placed under the dashboard, aerial should be placed in the top for... -
Page 21: Siren Sounds And Turn Light Signals
A battery in the radio tag is discharged 3 sound signals / 3 times Absence of the radio tag 5 sound signals / 5 times Blocking warning Fast sound singals PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 22: System Modules Layout
WE RECOMMEND YOU TO FILLING OUT INSTALLATION CERTIFICATE AND WARRANTY CARD BY INSTALLER. THESE DOCUMENTS MAY BE REQUIRED FOR CONTACTING CUS- TOMER SUPPORT. PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 23: Acceptance Certificate
INSTALLATION CERTIFCATE ACCEPTANCE CERTIFICATE I, the undersigned_________________________________________________________ Model Pandora DXL 1840L is in conformity with Electromagnetic Compatibility Directive EMC Position, name. 2004/108/EC and R&TTE Directive 1999/5/EC. ______________________________________________________________________________ professional installer, certify that installation of the service-security system, specified below, was carried Serial number ______________________________ Date of production___________________ out by me in accordance with manuals and schemes provided by the manufacturer. - Page 24 PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM USER MANUAL...
- Page 25 PANDORA DXL 1840L CAR SERVICE-SECURITY SYSTEM...
