Pandora Smart v3 is a car service-security system built for cars with on-board voltage of 12V. It
is a complex engineering solution, which includes unique and modern technological software and
hardware solutions.
When building the Pandora Smart v3 we were using the most up-to-date electronics best
manufacturers. The device is built using high-precision mounting and control machinery, thus we
guarantee highest possible quality, reliability and stable technical characteristics for the whole
operation period.
The Pandora Smart v3 has a cryptographically strong authorization code with unique dialog
algorithm and individual encryption key on every device. It guarantees protection form electronic
hacking for the whole operation period.
The system is built for your convenience: it's ergonomic, reliable, has the highest security and
service characteristics, 3 years unconditional warranty and free service and support. We are happy to
provide any support we can – feel free to use our online support.
!
WARNING! It's strongly recommended to install a security system by the qualified personnel!
The installer should be able to mount the system using provided documentation –
installation diagram, specific installation guides and special software developed and tested by
our engineers. Most of the features are depends of a correct connection and configuration of
the service-security system, so if the certain feature doesn't work as expected, most likely the
problem is related to improper installation.
This device has limited external factors resistance. It should be operated in temperatures outside from -40 to +85
components must be installed only in a car interior. The base unit and radio tags fulfil with the IP40 category of protection against water.
Our web-site: pandorainfo.com
Customer support: support@pandorainfo.com
Pandora would like to thank you for
choosing our service-security system
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
C range. All system
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart and is the answer not in the manual?

Questions and answers

Related Manuals for Pandora Smart

Summary of Contents for Pandora Smart

  • Page 1 Pandora would like to thank you for choosing our service-security system Pandora Smart v3 is a car service-security system built for cars with on-board voltage of 12V. It is a complex engineering solution, which includes unique and modern technological software and hardware solutions.

  • Page 2: Table Of Contents

    Table of contents General information Control by a phone System set Changing settings via a phone Read before using PIN-codes of the system Online service and mobile application Owner’s personal card External VALET button Control the system System modules layout Arming Base unit Disarming...

  • Page 3: System Set

    System set Read before using 1. User manual Carefully read this manual before starting installation and using the security-service system. Pay attention to text marked with 2. Owner’s card 3. Radio tag 4. External VALET button he securiTy and TelemeTric sysTem is a complex Technical producT ysTem insTallaTion and configuraTion musT be carried ouT only by a skilled professional 5.

  • Page 4: Owner's Personal Card

    PIN-codes of the system External VALET button The «Secret PIN-code» An external VALET button with a three-color status LED indicator is placed CANNOT BE CHANGED (is written on the «Owner’s personal card» inside a vehicle (see the system modules layout) The button is used for The «Service PIN-code»...

  • Page 5: Base Unit

    Base unit Built-in micro-USB port – update and configuration of the system using a PC and Pandora Alarm Studio or mobile app Pandora Specialist. Built-in GSM modem (2G/3G/4G LTE) provides a connection with our online-service pandora-on. com and mobile application Pandora Connect, voice and SMS notifications, automatic date and time...

  • Page 6: Information Signals Of The System

    Information signals of the system SOUND AND LIGHT SIGNALIZATION SIGNALS DESCRIPTION (sound / light) LED INDICATOR SIGNALS Arming 1х /1х SIGNALS DESCRIPTION Disarming 2х /2х THE SYSTEM IS ARMED Car search 5х /5х Short red flashes System is armed Alarm, PANIC mode 30 sec.

  • Page 7: System Functions And Modes

    SYSTEM FUNCTIONS AND MODES • «Parking light is not turned off» notification (status) • Shock sensor (security zone – alarm and warning level) Security mode • Motion sensor (security zone – alarm level) • Tilt sensor (security zone – alarm level) The system confirms arming with 1х...

  • Page 8: Slave Mode

    Owner authorization devices and functions 2. Turn the key in the ignition lock to the OFF position (the engine should still be running) and take it out of the lock (skip this step for cars with a Start/Stop button). 3. Leave the car, close the doors. Authorization devices 4.

  • Page 9: Checking The Number Of Paired Devices

    IMMOBILIZER RADIO TAG If the system cannot detect an authorization device, the base unit will perform a delayed engine blocking. The siren will play the «Engine blocking warning» ringtone before blocking. The engine will be blocked immediately or at the time the car starts moving, it depends on the system settings. When A radio tag is a device used to control a vehicle/system.

  • Page 10: Replacing An Immobilizer Tag Battery

    Light indication of SEND LED Updating firmware of the tag • Download the Pandora BT application (for Android or iOS devices equipped with a Bluetooth 4.0 Low SIGNAL DESCRIPTION Energy or higher module). • Open the mobile app Pandora BT.
  • Page 11 CONTROL THE SYSTEM BY A PHONE +XXXXXXXXXXX,123*,297* where «+XXXXXXXXXXX» – the system phone number, or The correcT operaTion of The funcTions an owner should moniTor The sTaTus balance of The card , gsm «,» - pause is a feature of the phone (can be displayed as the «P», see the instructions of the phone), insTalled in The sysTem f The card is blocked or defecTive...

  • Page 12: Changing Settings Via A Phone

    2. Dial 666* to block an engine or 999* to unlock it (after dialing 999* you should enter the «Secret Pandora systems have a function of prompt disabling automatic engine start: 1. Call the system number and wait for the answer.

  • Page 13: Online Service And Mobile Application

    Telemetric function of the system allows you to control pandora-on.com Second additional owner's Set threshold voltage for sending your vehicle using the online service pandora-on.com or number -> # text message mobile app – Pandora Connect (for iOS/Android). Account balance inquiry number -> #...
  • Page 14 Control via Bluetooth The Pandora Connect application can work via a Bluetooth channel when there is no connection to the server. This type of connection allows you to control the system, receive status information and use your mobile phone as an authorization device.

  • Page 15: Control The System

    Shortly press the «Unlock» button on an original remote control or use a sensor/button on a door handle Login to the PANDORA-ON.COM, when the system is online (there is an Internet connection) press the (for cars with an intelligent access system.

  • Page 16: Locking/Unlocking Doors When Ignition Is On

    PANIC mode Online service Login to the PANDORA-ON.COM, when the system is online (there is an Internet connection) press the button on the control panel. If your car or you are in danger and you want to draw attention to your car, you can use PANIC mode.

  • Page 17: Remote Engine Start

    «Immobilizer PIN-code» (if the «Code immobilizer» function is used) and use one of the method described below: • To start the engine, login to the PANDORA-ON.COM (when the system is online there is an Internet connection), press the START ENGINE button on the control panel. In a few seconds the engine will be started, it will be confirmed with the spinning icon.

  • Page 18: Control The System In Case Of Emergency

    • To deactivate service mode dial the DTMF command. device, vehicle battery charge level, gearbox selector position, check information on the dashboard. dTmf Mobile application Pandora Connect he sysTem can be conTrolled from a phone using commands 0* – Disarming.

  • Page 19: Emergency Disarming

    • Enter the fourth digit • Press the button the number of times equal to the fourth digit. Pauses Enter the «Secret PIN-code» or the «Service PIN-code» (default value is 1-1-1-1) to put the system in between presses should not exceed 1 second. Each pressing will be confirmed with an orange LED programming mode.

  • Page 20: Additional Devices

    ADDITIONAL DEVICES Radio module RHM-03 BT – is a wireless device designed to control equipment of the engine compartment: Remote control D-030 is a two-way short-distance communication • Control of Hood lock, siren, engine blocking based or not based on device designed to control a security system and receive information car movement, digital control of engine pre-heaters Eberspacher about its state.

  • Page 21: Warranty Obligations

    WARRANTY OBLIGATIONS Manufacturer guarantees correct operation of the service-security system if exploitation, installation, storage and transportation conditions described in this manual were met. The system should only be used according to installation scheme and user manuals. The system is meant to be installed by the professional car electronics installers. The installer should fill in installation certificate that is included in this manual.

  • Page 22: Installation Certificate

    Car specifications: Car model____________________________________________ Type ____________________________ Id number (VIN)_______________________________________________________________________ Registration number____________________________________________________________________ Security system specification: Model Pandora Smart v3 Serial number_________________________________________________________________________ Service center name, full address and installer’s stamp ____________________________________________________________________________________ ____________________________________________________________________________________ Signature_____________________/___________________________________/...

  • Page 23: Acceptance Certificate

    ACCEPTANCE CERTIFICATE Model Pandora Pandora Smart v3 is in conformity with Electromagnetic Compatibility Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC. Serial number ______________________________ Date of production__________________________ Responsible person’s signature (stamp) Packager_____________________________________________________________________________ Signature (personal stamp) _____________________________________________________________________________________ WARRANTY CARD Model Pandora Smart v3 Serial number ________________________________________________________________________ Date of purchase «____»...
