Pandora DXL 1200L is a security-service system specially designed for motorcycles.
It is a complex engineering solution, which includes security system, telemetry, remote and auto-
matic engine start and various service options.
When building Pandora DXL 1200L we were using the most up-to-date electronics from world's
best manufacturers. The device is built using high-precision mounting and control machinery, thus we
guarantee highest possible quality, reliability and stable technical characteristics for the whole opera-
tion period.
Pandora DXL 1200L has a cryptographically strong authorization code with unique dialog algo-
rithm and individual 128-bit encryption key on every device. We guarantee 100% protection form elec-
tronic hacking for the whole operation period.
The system is built for your convenience: its ergonomic, reliable, has the highest security and service
characteristics, 3 years unconditional warranty and free service and support on the territory of Russian
Federation and nearest states. We are happy to provide any support we can – feel free to use our online
support.
WARNING! IT IS STRONGLY ADVISED TO HAVE PROFESSIONAL VEHICLE ME-
CHANIC INSTALLING THE SYSTEM. ANY VEHICLE ELECTRONICS INSTALLER
SHOULD BE ABLE TO INSTALL PANDORA SYSTEM USING INSTALLATION SCHEME
IN THIS MANUAL AND ALARMSTUDIO SOFTWARE. MOST FEATURES ARE HIGHLY
DEPENDENT ON COMPETENT INSTALLATION. OUR SYSTEMS ARE THOROUGHLY
TESTED FOR QUALITY, SO IF A FEATURE FAILS TO PRODUCE EXPECTED RESULTS,
MOST LIKELY THE PROBLEM IS IN IMPROPER INSTALLATION
This device has limited external factors resistance. It should not be operated in temperatures outside -40 to +85° C range.
IMPORTANT! Note that this manual describes remote and manual functions for the most
part. Functionality of the system is vast and would require a book-sized manual to fully describe.
Instead we use handy software named AlarmStudio that functions as both programming tool and
an extended installation & functionality manual. It requires Windows and can be downloaded at
pandorainfo.com
www.pandorainfo.com
Our web site:
Customer support:
support@pandorainfo.com
Pandora would like to thank you for choosing
our DXL 1200L service and security system
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
EN
Advertisement
Chapters
Table of Contents
Related Manuals for Pandora DXL 1200L
Summary of Contents for Pandora DXL 1200L
- Page 1 It is a complex engineering solution, which includes security system, telemetry, remote and auto- matic engine start and various service options. When building Pandora DXL 1200L we were using the most up-to-date electronics from world’s best manufacturers. The device is built using high-precision mounting and control machinery, thus we guarantee highest possible quality, reliability and stable technical characteristics for the whole opera- tion period.
-
Page 2: Table Of Contents
• Built-in integral accelerometer for determining motion and shocks with adaptive processing Programming the system algorithm and sensitivity controls Programming the system using Pandora Alarm Studio • Built-in temperature sensor, socket for additional temperature sensor Programming using the VALET button •... -
Page 3: Security Mode
3 times in a row. When switching on the ignition, the base unit of Pandora security system performs a search for immobilizer tags in radio zone. If no radio tags were detected when the ignition is switched on, the Radio tag system will block the engine. -
Page 4: Backup Battery
(if ”Disable disarming when the tag is not present” setting is enabled, disarming procedure will be performed only if there is a tag in the radio zone). Log in to the PANDORA-ON.COM. When thy system is active, press and hold the button on the control panel. -
Page 5: Remote And Automatic Engine Start
ENGINE with the fading of engine operation icon THESYSTEM IS INSTALLED, PLEASE CHANGE FACTORY SET PIN-CODE. 1-2-3-4. Internet service Log in to the pandora-on.com. When thy system is active, press and hold the button on the START ENGINE control panel. In a few seconds the engine will be started, it will be confirmed with the spinning engine DTMF –... -
Page 6: Changing Settings Via A Phone
REPEAT THE LAST MESSAGE To repeat any message, press * during a voice call to the system ENABLING/DISABLING AUTOMATIC ENGINE START Owner's number -> # Changing guest PIN-code Pandora system has function of promptly disabling automatic engine start. Phone Additional number settings settings 1. -
Page 7: Online Service Pandora-On.com And Mobile Applications
‘SECRET PIN-CODE’ . Control via radio channel Mobile applications Pandora Online and Pandora Pro can control the system, receive status information and open advanced settings without Internet connection when the phone is in the Bluetooth coverage WARNING! CAREFULLY REMOVE THE PROTECTIVE LAYER, DO NOT USE SHARP OB- zone. -
Page 8: Enabling/Disabling Immobilizer Radio Tag
Enter the “Service PIN-code” to enter programming mode (factory preset of the service PIN-code momentary normally open switch and the 3V LED indicator is ‘1-1-1-1’). You can enter the code only if the base unit is powered, the ignition is switched off, the MOTORCYCLE SERVICE-SECURITY SYSTEM PANDORA DXL 1200L USER MANUAL... -
Page 9: Programming The System
To program using a computer, you need a standard USB cable, a computer maximum load current 200mA. This output is used to control ignition relay for remote and automatic with Windows XP/Vista/7/8/10 and Pandora AlarmStudio application (you can download it from engine starts and for “in series (incut)” connection of the ignition. -
Page 10: Programming Using The Valet Button
Tags are recorded (paired) one by one, in any order and Pandora Alarm Studio will automatically connect to the system and open access to the settings and without time limit. All previously registered radio tags will be removed when you overwrite new tags firmware updates. - Page 11 This sublevel is used to select active buttons via ‘Code Immobilizer’ analog input. To determine the LED indicator will light green after entering the level. Open ‘Pandora Online’ mobile application, go activity of the analog ”Code Immobilizer” input, apply potential to the corresponding input (INP) of the to ‘Bluetooth Control’...
-
Page 12: Additional Devices
Levels 19, 20, 21, 22, 25, 26 – Updating firmware of additional Bluetooth devices activated immediately or when determining motion with built-in Download the firmware from www.pandorainfo.com and install Pandora BT application on your accelerometer, it depends on the system configuration). The module mobile device. -
Page 13: Meaning Of Indicator Led Colors
The system will emit short sound signals from a siren with less than 1 sec. interval. The number of the signals equals to the number of recorded tags. After a pause of 2 seconds the system signal will indicate registered mobile device. MOTORCYCLE SERVICE-SECURITY SYSTEM PANDORA DXL 1200L USER MANUAL... -
Page 14: Installation Certificate
Vehicle specifications: Vehicle model _______________________________________________________________________________________ Type ______________________________________________________________________________________________ Pandora DXL 1200L è il sistema di sicurezza e di protezione progettato per il montaggio su moto. ID number (VIN) _____________________________________________________________________________________ Realizzato dagli ingegneri russi altamente qualificati il prodotto comprende una vasta gamma di Registration number _________________________________________________________________________________ soluzioni tecnologiche avanzate di ingegneria, software e hardware. -
Page 15: Componenti Del Sistema
• Controllo del funzionamento del motore - contagiri (controllo) • Neutro (controllo) • Attivazione del sensore aggiuntivo (controllo, protezione - livello di allarme e livello precauzionale) SISTEMA DI SICUREZZA E PROTEZIONE PER LE MOTOCICLETTE PANDORA DXL-1200L MOTO GSM MANUALE OPERATIVE... -
Page 16: Zone Del Sistema
”Immobilizer”, ”HandsFree”, ”Slave”. Il tag radio ha in più un pulsante di controllo per l’inserimento/disinserimento antifurto e attivazione SISTEMA DI SICUREZZA E PROTEZIONE PER LE MOTOCICLETTE PANDORA DXL-1200L MOTO GSM MANUALE OPERATIVE... -
Page 17: Alimentazione Di Emergenza
Armare senza segnale sonoro della sirena, immettere il numero di comando App mobile Apri l’applicazione mobile. Quando il tuo sistema è attivo, tieni premuto il pulsante sul pannello di controllo fino a quando non ha completato la funzione. SISTEMA DI SICUREZZA E PROTEZIONE PER LE MOTOCICLETTE PANDORA DXL-1200L MOTO GSM... -
Page 18: Base Unit
VALET button CH3/INP6 – Starter control output 200mA Blue CH2/INP5 – Ignition control output GPS/GLONASS Pandora * When CH6 is assigned as NC Blocking DXL 1200L **Set input type to NC if a reed sensor is used SMART MOTO v.1.0... -
Page 19: Disinserimento Antifurto
Il servizio online Fare l’ingresso al sito pandora-on.com, al momento dello stato attivo del sistema, premere il pulsante sul pannello di controllo. Pulsante ”VALET” Premere e tenere premuto il pulsante ”VALET” per 3 secondi, quindi rilasciate il pulsante. Dopo 30 secondi, il trasporto verrà armato, nel periodo di riferimento di tempo, l’indicatore di stato ”LED” si illumina in rosso. -
Page 20: La Gestione Del Sistema Dal Telefono
9 * (”stella”), ascoltare le informazioni sui comandi di gestione del sistema. Per completare il 1. VIA A TELEFONO, UTILIZZANDO IL MENU DELLE IMPOSTAZIONI DEL CORE. 2. CON L’AIUTO DI UN COMPUTER E IL SOFTWARE SPECIALE PANDORA ALARM STUDIO. collegamento, riagganciare. -
Page 21: Descrizione Dei Connettori
Connettore è utilizzato per configurare e aggiornare il sistema tramite un cavo USB di interfaccia Il sistema passerà nella modalità di programmazione delle impostazioni: collegato a un computer con il software precaricato di Pandora Alarm Studio. Esempio del cambio numero di telefono del proprietario dell’antifurto: Connettore X2 (Il pulsante del telecomando ”LED/VALET”) -
Page 22: Servizio Online Informativo Pandora-On.com E Applicazioni Mobili
Controllo radio magnetico (contatto sigillato) è necessario cambiare il canale operativo logico ”Tipo di ingresso” con NO Applicazioni mobile Pandora Online e Pandora Pro possono controllare il sistema, ricevere a NC nelle impostazioni ”Ingressi/uscite”. informazioni sullo stato e aprire le impostazioni avanzate senza connessione Internet quando il telefono •... -
Page 23: Gestione Del Sistema In Caso D'emergenza
LED verde. Dopodiché, il sistema • Inserire la terza cifra del codice utilizzando il pulsante tornerà al menu di programmazione. VALET. Pulsante ”VALET” SISTEMA DI SICUREZZA E PROTEZIONE PER LE MOTOCICLETTE PANDORA DXL-1200L MOTO GSM MANUALE OPERATIVE... -
Page 24: Configurazione E Programmazione Del Sistema
Registrazione del sensore wireless N.1, N.2 (DMS-100 BT) e il cavo USB PC, computer con il sistema operativo XP/Vista/ Win 7 (8, 9, 10) e un software speciale Pandora Alarm Studio (la versione attuale può essere scaricata dal sito web www.alarmtrade.ru). Livello 25, 26 Aggiornamento del sensore wireless N.1, N.2 (DMS-100 BT) -
Page 25: Segnali Di Sirena E Segnalazione Luminosa
λύσεις, καθώς και τις λύσεις λογισμικού και εξοπλισμού. (dati segnali sono disponibili al collegamento aggiuntivo) Κατά το σχεδιασμό του συστήματος Pandora DXL 1200L χρησιμοποιήθηκαν τα πιο σύγχρονα ηλεκτρονικά εξαρτημάτα απο τους καλύτερους κατασκευαστές. Το προϊόν κατασκευάστηκε με τη χρήση του καινούργιου εξοπλισμού υψηλής ακρίβειας για την εγκατάσταση των εξαρτημάτων και τον... - Page 26 • Έλεγχος της λειτουργίας του κινητήρα - ταχύμετρο (έλεγχος) • Κιβώτιο ταχυτήτων - Neutral (έλεγχος) • Ενεργοποίηση του πρόσθετου αισθητήρα (έλεγχος, προστασία – επίπεδο συναγερμού και προειδοποίησης) ΣΥΣΤΗΜΑ ΑΣΦΑΛΕΙΑΣ ΚΑΙ ΕΞΥΠΗΡΕΤΗΣΗΣ ΓΙΑ ΔΙΚΥΚΛΑ ΟΧΗΜΑΤΑ PANDORA MOTO GSM DXL 1200L ΟΔΗΓΙΕΣ ΛΕΙΤΟΥΡΓΙΑΣ...
- Page 27 • Μπαταρία CR 2032 Η λειτουργία είναι απενεργοποιημένη ως προεπιλογή, για την ενεργοποίησή της πρέπει να εκτελέσετε • Συχνότητα 2,4 GHz (κρυπτογράφηση AES-128) πρόσθετη σύνδεση και ρύθμιση. ΣΥΣΤΗΜΑ ΑΣΦΑΛΕΙΑΣ ΚΑΙ ΕΞΥΠΗΡΕΤΗΣΗΣ ΓΙΑ ΔΙΚΥΚΛΑ ΟΧΗΜΑΤΑ PANDORA MOTO GSM DXL 1200L ΟΔΗΓΙΕΣ ΛΕΙΤΟΥΡΓΙΑΣ...
- Page 28 ενσωματωμένη μπαταρία είναι αποφορτισμένη το σύστημα θα ξεκινήσει αυτόματα τη φόρτιση της την δευτερόλεπτα το όχημα θα είναι υπό την προστασία της Pandora, κατά τη διάρκεια της χρονομέτρησης στιγμή που θα λειτουργήσει ο κινητήρας και η τάση θα είναι άνω των 13 V.
- Page 29 Υπηρεσία Διαδικτύου Για εφαρμογή της λειτουργίας ”Εκκίνηση του κινητήρα με ένα κλικ” από το μη βασικό νούμερο του Συνδεθείτε με την ιστοσελίδα pandora-on.com, ενώ το σύστημα είναι ενεργό, κάντε κλικ στο ιδιοκτήτη πρέπει να δημιουργηθεί η επαφή στην ακόλουθη μορφή: κουμπί...
- Page 30 ήνυ α αν η παταρία είναι χα ηλή ήνυ α σε περίπτωση ατυχή ατο διακόπτη παροχή (ανα ένο /σβηστο ) Ρύθ ιση του διακόπτη παροχή Anti-Hi-Jack ΣΥΣΤΗΜΑ ΑΣΦΑΛΕΙΑΣ ΚΑΙ ΕΞΥΠΗΡΕΤΗΣΗΣ ΓΙΑ ΔΙΚΥΚΛΑ ΟΧΗΜΑΤΑ PANDORA MOTO GSM DXL 1200L ΟΔΗΓΙΕΣ ΛΕΙΤΟΥΡΓΙΑΣ...
- Page 31 Η υποδοχή προορίζεται για ρύθμιση και αναβάθμιση του συστήματος μέσω του καλωδίου-USB το οποιεσδήποτε συνθήκες μέχρι να σβήσει η ανάφλεξη. οποίο είναι συνδεδεμένο με τον υπολογιστή και το πρόγραμμα Pandora Alarm Studio (μόνο για τεχνικούς εγκαταστάτες). • Καλώδιο ”10” (καφέ-άσπρο) (-) INP1 — εργοστασιακή ρύθμιση ”Πορτ-μπαγκάζ”, αρνητική...
- Page 32 είναι όχι από τον αριθμό του ιδιοκτήτη, εισάγετε τον ”Κωδικό PIN του επισκέπτη” (Εργοστασιακή 1-2- 3-4). Οι εφαρμογές για κινητά Pandora Online και Pandora Pro, αφού βρίσκονται σε κοντινή απόσταση (στην περιοχή σύνδεσης Bluetooth), μπορούν να διαχειριστούν, να λάβουν πληροφορίες για την...
- Page 33 σβηστή, το σύστημα αφοπλισμένο και απενεργοποιημένη τη λειτουργία συντήρησης. Αν δεν υπάρχει ο ”Service PIN-κωδικού” η εισόδος στο μενού προγραμματισμού είναι δυνατή μετά την εισαγωγή του ”ΜΥΣΤΙΚΟΥ ΚΩΔΙΚΟΥ PIN”, που βρίσκεται στην ατομική πλαστική κάρτα του ιδιοκτήτη. ΣΥΣΤΗΜΑ ΑΣΦΑΛΕΙΑΣ ΚΑΙ ΕΞΥΠΗΡΕΤΗΣΗΣ ΓΙΑ ΔΙΚΥΚΛΑ ΟΧΗΜΑΤΑ PANDORA MOTO GSM DXL 1200L ΟΔΗΓΙΕΣ ΛΕΙΤΟΥΡΓΙΑΣ...
- Page 34 του προσωπικού υπολογιστή, χρειάζονται ένας υπολογιστής με το λειτουργικό σύστημα XP/Vista/Win7 Ανανέωση λογισμικού Bluetooth της μονάδας (RHM-03 BT) (8, 9, 10) και το συγκεκριμένο λογισμικό Pandora Alarm Studio (μπορείτε να κατεβάσετε την τρέχουσα Επίπεδο 21 έκδοση του προγράμματος από την ιστοσελίδα www.pandorainfo.com).
- Page 35 της σειρήνας με κενό λιγότερο από 1 δευτερόλεπτο θα ειδοποιήσει για την παρουσία καταχωρημένων Tags, δύο δευτερόλεπτα μετά από την παύση θα ειδοποιήσει για την παρουσία του κινητού τηλεφώνου. ΣΥΣΤΗΜΑ ΑΣΦΑΛΕΙΑΣ ΚΑΙ ΕΞΥΠΗΡΕΤΗΣΗΣ ΓΙΑ ΔΙΚΥΚΛΑ ΟΧΗΜΑΤΑ PANDORA MOTO GSM DXL 1200L...
