Pandora DXL 1940L is a premium car service-security system, built for cars with on-board voltage
of 12V. It is a complex engineering solution which includes car security system, telemetry, remote and
automatic engine start and various service options, all controlled from your OEM key remote, smart-
phone or online service.
When building Pandora DXL 1940L we were using the most up-to-date electronics from world's
best manufacturers. The device is built using high-precision mounting and control machinery, thus we
guarantee highest possible quality, reliability and stable technical characteristics for the whole opera-
tion period.
Pandora DXL 1940L has a cryptographically strong authorization code with unique dialog algo-
rithm and individual 128 bit encryption key on every device. We guarantee 100% protection form elec-
tronic hacking for the whole operation period.
The system is built for your convenience: it's ergonomic, reliable, has the highest security and service
characteristics, 3 years unconditional warranty and free service and support on the territory of Russain
Federation and nearest states. We are happy to provide any support we can – feel free to use our
online support.
WARNING! IT IS STRONGLY ADVISED TO HAVE PROFESSIONAL CAR MECHANIC
INSTALLING THE SYSTEM. ANY CAR ELECTRONICS INSTALLER SHOULD BE ABLE
TO INSTALL PANDORA DXL 1940L USING INSTALLATION SCHEME IN THIS MANU-
AL AND ALARMSTUDIO SOFTWARE. MOST FEATURES ARE HIGHLY DEPENDENT
ON COMPETENT INSTALLATION. OUR SYSTEMS ARE THOROUGHLY TESTED FOR
QUALITY, SO IF A FEATURE FAILS TO PRODUCE EXPECTED RESULTS, MOST LIKELY
THE PROBLEM IS IN IMPROPER INSTALLATION
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40 to +80° C range. All system components must be installed only in a car interior..
IMPORTANT! Note that this manual describes remote and manual functions for the most
part. Functionality of the system is vast and would require a book-sized manual to fully describe.
Instead we use handy software named AlarmStudio that functions as both programming tool and
an extended installation & functionality manual. It requires Windows and can be downloaded at
pandorainfo.com
Our web site:
www.pandorainfo.com
Customer support:
Pandora would like to thank you for choosing our
support@pandorainfo.com
DXL 1940L service and security system
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
Advertisement
Table of Contents
Related Manuals for Pandora DXL 1940L
Summary of Contents for Pandora DXL 1940L
- Page 1 Pandora would like to thank you for choosing our DXL 1940L service and security system Pandora DXL 1940L is a premium car service-security system, built for cars with on-board voltage of 12V. It is a complex engineering solution which includes car security system, telemetry, remote and automatic engine start and various service options, all controlled from your OEM key remote, smart- phone or online service.
-
Page 2: Table Of Contents
Online service and mobile application Installation and configuration of the system Installation requirements Wiring diagram RMD-5M connection diagram Wiring description Programming the systems Preparing to program the system using a computer Updating firmware Additional devices PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 3: Car Security Zones
SYSTEM FEATURE Car security zones Base unit Pandora DXL 1940L service-security system guards following independent zones: • Android and iOS applications. • car doors perimeter • Individual PIN-code to disarm and switch off immobilizer. • front hood triggers • Hands Free mode for arming/disarming. -
Page 4: Control Over The System
This mode is enabled by default. Use a phone to disable this mode (see ‘Control over system via a phone’ To arm/disarm the system, RF tag should be in the Bluetooth coverage section). When switching on the ignition, the base unit of Pandora security system performs a search area. The system produces a protected (AES-128 encryption) interac- for immobilizer tags in radio zone. -
Page 5: Anti-Hi-Jack-2 Mode
To enable the maintenance mode, disarm the system, switch on the ignition, the radio tag should This mode is disabled by default. Use Pandora Alarm Studio application to enable this mode. Anti- be in the coverage zone (if the immobilizer/AntiHijack function is activated), enter the ‘Immobilizer PIN- Hi-Jack-2 mode helps to prevent aggressive seizure of the car using delayed engine blocking on radio code’... -
Page 6: Control Over The System In Case Of Emergency
LED indicator flash. A Pause for more than 1 second and a red LED indicator flash confirm the input of the first digit. Then you can enter the next digit. PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 7: Enabling/Disabling Immobilizer Radio Tag
+XXXXXXXXXXX,123*,297* where ‘+XXXXXXXXXXX’ – the system phone number, ‘ , ’ - pause is a feature of the phone (can be displayed as the ‘P’ , see the instructions of the phone), ‘123*’ - remote engine start DTMF command, PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL... - Page 8 1. Call the system number. Wait for answer. Arming/disarming 2. Dial 500*. Pandora system has function of promptly disabling automatic engine start. 3. The system will confirm: ‘Current coordinate sent via text message’ and will send text message 1. Call the system number. Wait for answer.
-
Page 9: Changing Settings Via Phone
Voice calls when radio relay 1. VIA A PHONE, USING CORE SETTINGS MENU. connection is lost Settings of the warning level of the 2. VIA A COMPUTER AND PANDORA ALARMSTUDIO SOFTWARE shock sensor sensitivity Voice calls when on-board voltage Sensor... -
Page 10: Online Service And Mobile Application
ONLINE SERVICE AND MOBILE APPLICATION Control via radio channel Mobile applications Pandora Online and Pandora Pro can control the system, receive status infor- Warning! For the correct operation of the GSM mation and open advanced settings without Internet connection when the phone is in the Bluetooth pandora-on.com... - Page 11 Arming 09:00 165 Fleet St, London EC4A 2DY, UK 09:00 Automatic Hands Free Tracking Voice calls engine start Automatic Siren Text switching on mode receiver connection messages of the engine preheater PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL...
-
Page 12: Installation And Configuration Of The System
Motion Left front Left rear Warning zone sensor door door of the supplementary sensor Enter system Loss Trunk programming of GSM mode connection PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL... - Page 13 DXL 1940L For remote engine start implementation IMMO-KEY2 OUT Black CH9 - Bypass IMMO-KEY1 IN Green White (–) CH6 - NO blocking Blue IMMO-KEY1 OUT (–) Green CH10 - Starter Yellow (–) CH7 - ACC (Brake pedal*) Orange (–) CH8 - Ignition...
-
Page 14: Wiring Description
WIRING DESCRIPTION Brown Х5 socket (main socket): Yellow RMD-5M Relay module Orange • Wire «1» (White) (Tachometer input) — analog input of the tachometer signal, it connects to Green/Red the tachometer wire or to the signal wire of a nozzle, which provide stable pulses of any polarity cor- Blue/Red responding to the RPM. -
Page 15: Programming The Systems
LED indicator flash. A pause for more than 1 second and a red LED indicator flash confirm the and connecting to ignition in series (incut). If ‘Car with START/STOP button’ setting is enabled, the channel input of the first digit. Then you can enter the next digit. PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 16: Preparing To Program The System Using A Computer
Level 15 Emergency disabling of immobilizer radio tag It is required to create an account in AlarmStudio to use Pandora CLONE for remote engine start (you can register without a connection to a system). Pandora CLONE procedure requires Internet connection. - Page 17 LED indicator. The system will exit programming menu and the series of red and green flashes of status LED indicator will confirm the saving. reboot after saving the idle speed. PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL...
- Page 18 If you determine buttons via digital protocol select one or more buttons (up to four) for entering the secret code of the immobilizer. To do this press the selected button, LED indicator will confirm input PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL...
- Page 19 LED light. After that the system will return to the programming menu. LED indicator will light green after entering the level. Open ‘Pandora Online’ mobile application, go to ‘Bluetooth Control’ –> ‘Not specified’ menu (‘Bluetooth device’ for iOS). This setting will be available after adding the system in the account.
-
Page 20: Additional Devices
Level 19, 20, 21, 22, 25, 26 – Updating firmware of additional Bluetooth devices programming Download the firmware from www.pandorainfo.com and install Pandora BT application on your mobile device. To update firmware of additional devices, enter the programming mode and press VALET button the number of times equals to the desired level number (see the Programming levels table). -
Page 21: Siren Sounds And Turn Light Signals
2 sound signals A battery in the radio tag is discharged 3 sound signals / 3 times Absence of the radio tag 5 sound signals / 5 times Blocking warning Fast sound singals PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 22: Meaning Of Indicator Led Colors
The system will emit short sound signals from a siren with less than 1 sec. interval. The number of the signals equals to the number of recorded tags. After a pause of 2 seconds the system signal will indicate registered mobile device. PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 23: Warranty Obligations
Work accepted__________________/___________________________________/ Signator Date «____»___________________20___year. WE RECOMMEND YOU TO FILLING OUT INSTALLATION CERTIFICATE AND WARRANTY CARD BY INSTALLER. THESE DOCUMENTS MAY BE REQUIRED FOR CONTACTING CUS- TOMER SUPPORT. PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM USER MANUAL... -
Page 24: Acceptance Certificate
ACCEPTANCE CERTIFICATE Model Pandora DXL 1940L is in conformity with Electromagnetic Compatibility Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC. Serial number ______________________________ Date of production___________________ Responsible person’s signature (stamp) Packager______________________________________________________________________ Signature (personal stamp) WARRANTY CARD Model Pandora DXL 1940L Serial number _________________________________________________________________ Date of purchase «____»... - Page 25 PANDORA DXL 1940L CAR SERVICE-SECURITY SYSTEM...
