Pandora is a brand of Russian Experimental Engineering Factory, a full production cycle
electronics R&D facility. We design and produce car service-security systems for more than 10 years
and have reached a considerable success on Russian and post-communist markets – biggest security
system markets in the world. Our systems are made to withstand severe weather conditions and
criminal situation of northern Eurasia.
Pandora DXL-0100L/0101L is a car service-security system, built for cars with on-board voltage
of 12V. It is a complex engineering solution which includes car security system, algorithmic security
that detects various events and immobilizer with possible RF tags, all controlled from your OEM key
remote. This system is designed to be all-in-one car security solution and requires no additional
modules. Note that 'no tags' version can be complemented with RF immobilizer tags sold separately,
or immobilizer can be controlled with a PIN dialed using original car buttons.
WARNING!
IT IS STRONGLY ADVISED TO HAVE PROFESSIONAL CAR MECHANIC INSTALLING
THE SYSTEM. CERTIFIED INSTALLERS ARE RARE OUTSIDE RUSSIA, BUT ANY CAR
ELECTRONICS INSTALLER SHOULD BE ABLE TO INSTALL PANDORA DXL-0050L
USING INSTALLATION SCHEME IN THIS MANUAL AND ALARMSTUDIO SOFTWARE.
MOST FEATURES ARE HIGHLY DEPENDENT ON COMPETENT INSTALLATION.
OUR SYSTEMS ARE THOROUGHLY TESTED FOR QUALITY, SO IF A FEATURE FAILS
TO PRODUCE EXPECTED RESULTS, MOST LIKELY THE PROBLEM IS IN IMPROPER
INSTALLATION.
It is essential for systems functioning that you read and understand instructions in this manual.
Note that all radio devices are subject to interference, which could affect proper performance.
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40 to +80
IMPORTANT! Note that this manual describes remote and manual functions for the
most part. Functionality of the system is vast and would require a book-sized manual to
fully describe. Instead we use a handy software named AlarmStudio that functions as both
programming tool and an extended installation & functionality manual. It requires Windows
and can be downloaded at pandorainfo.com
Pandora would like to thank you for choosing our
DXL-0100L/0101L service and security system
C range.
o
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
Advertisement
Table of Contents
Related Manuals for Pandora Mini
Summary of Contents for Pandora Mini
- Page 1 Pandora would like to thank you for choosing our DXL-0100L/0101L service and security system Pandora is a brand of Russian Experimental Engineering Factory, a full production cycle electronics R&D facility. We design and produce car service-security systems for more than 10 years and have reached a considerable success on Russian and post-communist markets –...
-
Page 2: Table Of Contents
Programming system and entering PIN-code Changing core settings via computer Configuring system settings via the wireless interface 2,4 GHz Entering the programming menu using VALET button Changing core settings via VALET button Wiring diagram Pandora DXL-0100L/0101L service-security system User manual... -
Page 3: General Information
• CR-2032 battery. Car security zones Pandora DXL-0100L/0101L service-security system guards following independent zones with corresponding zone notifications on the remote and recording alarms into the event history: • car doors perimeter (separate for every door) •... -
Page 4: Control Over System
2,4 GHz on one of This mode is enabled by default. When engine is running, base unit of Pandora security system 125 channels. To arm the system when the ignition is switched off, performs a search for immobilizer tags in radio zone. -
Page 5: Replacing Immobilizer Tag Battery
3. The system will confirm correct PIN-code with red and green flashes of LED indicator. If the input was incorrect, it will be indicated with long red flash. New input can be attempted after 5 seconds. Pandora DXL-0100L/0101L service-security system User manual... -
Page 6: Installation And Configuration Of The System
This input is • All unused system wires during the installation must be insulated and secured to prevent multipurpose, it can operate in accordance with selected logic. accidental touching of a car body or other wires. Pandora DXL-0100L/0101L service-security system User manual... -
Page 7: Programming System And Entering Pin-Code
If base unit has not yet been installed in the vehicle, it should be powered via micro-USB cable while programming. To program using a computer connected via cable, you need a standard micro-USB cable, a computer with Windows and a special piece of software – Pandora AlarmStudio. Programming system and entering PIN-code In preparation to the programming following stages should be followed: The system settings can be changed via computer. -
Page 8: Configuring System Settings Via The Wireless Interface 2,4 Ghz
Programming validator code of immobilizer (Pin to Drive) After the input is complete, the indicator fades, the system awaits a new programming level input. Level 12, 13, 14 Reserved Level 15 Emergency disabling of immobilizer Pandora DXL-0100L/0101L service-security system User manual... - Page 9 (–) 200mA OUT 3 • ENGINE BLOCK Yellow INP 2 • IGNITION SWITCH Purple (+) 2A SIREN GROUND +12V (+) Fuse 3A POWER +12V INP-5 Siren OUT-4 Ignition INP-1 OUT-3 OUT-5 CAN2 OUT-2 CAN1 Pandora LED/VALET INP-3 DATA TX DATA RX...
- Page 10 10, the system will confirm the entering with red flash of LED indicator. The system will await a wireless connection from the computer for 2 minutes. If the waiting time limit has expired and the Pandora DXL-0100L/0101L service-security system User manual...
-
Page 11: Additional Devices
Radio relay can be programmed on level 6 and 7. Level 5 is used to program engine compartment module RHM-02. For Pandora DXL-0100L/0101L optionally blocking RR-100 radio relay is available. Blocking radio relay with built-in accelerometer should be placed in the engine compartment. Herewith zone of 1. -
Page 12: Programming Mode (Recording) Of Rhm-02 Module
Wire 4 (White) is analog tachometer input, this wire should be connected to wire of tachometer or signal wire of injector, a wire with stable impulses of any polarity that correspond with motor shaft rotation frequency. Pandora DXL-0100L/0101L service-security system User manual... -
Page 13: Important Information
RF tag battery is discharged. Replace it. disarmed using RF tag button. Lit red The system is preparing for automatic arming Red and green flashes PIN-code confirmed, immobilizer disabled Faded The system is disarmed Pandora DXL-0100L/0101L service-security system User manual... -
Page 14: Glossary Of Terms
(e.g. seat heating, light path, additional block relays). Any channel (output) can be set as timer channel, that can be activated from the remote, or incorporated into scheduled and sequential routines. To assign timer channels, use AlarmStudio. Pandora DXL-0100L/0101L service-security system User manual... - Page 15 Pandora DXL-0100L/0101L service-security system User manual...
-
Page 16: Warranty Obligations
Packaged products should be stored on racks in piles of 6 or less boxes, in enclosed, dry, heated Work accepted________________/___________________________________/ rooms (no less than 1m from heating) which exclude possible interaction with moisture, oil products Signator and damaging environmental factors. Date «____»___________________20___y Pandora DXL-0100L/0101L service-security system User manual... -
Page 17: Acceptance Certificate
Acceptance certificate Pandora DXL-0100L/0101L is in conformity with Electromagnetic Compatibility Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC Serial number ______________________________________________ Date of production _________________________________________________ Responsible person’s signature (stamp) Packager ___________________________________________________ Signature (personal stamp) Warranty card Model Pandora DXL-0100L/0101L Serial number ______________________________________________ Date of purchase «____»...
