Pandora would like to thank you for choosing
our LIGHT PRO service and security system

Advertisement

Table of Contents
loading

Related Manuals for Pandora LIGHT PRO

Summary of Contents for Pandora LIGHT PRO

  • Page 1 Pandora would like to thank you for choosing our LIGHT PRO service and security system...

  • Page 2: General Information

    10 years of experience in the development of car-alarms making it able to offer the latest technology with unique features. In 2016, Pandora and TSS Group, have formed a new strategic partnership and thanks to long experience in the car security market, the selected functions and features have been optimized according to needs of EU and european customers.
  • Page 3 G E N E R A L I N F O R M A T I O N IMPORTANT! Note that this manual describes remote and manual functions for the most part. Functionality of the system is vast and would require a book-sized manual to fully describe.

  • Page 4: Table Of Contents

    PANIC mode Remote and automatic engine start Programmed neutral procedure (for cars with manual transmission) Remote engine start System settings menu Engine preheater Timer channels control Car status control Event history Automatic engine start settings PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...
  • Page 5 T A B L E O F C O N T E N T S Sensors settings Shock sensor settings Motion sensor settings Tilt sensor settings Wiring diagram Wiring description Siren signal settings Sound notification settings Radio channel control settings Maintenance mode Time settings Alarm settings...
  • Page 6 Preparing to program the system using a computer Updating firmware Programming using VALET button Additional devices Siren sounds and turn light signals Meaning of LED indicator colors Checking the number of recorded remote controls/ radio tags/mobile device PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 7: System Features

    S Y S T E M F E T U R E S SYSTEM FETURES 2-way LCD remote control • Arming and disarming security system using separate buttons. • Statuses of 14 independent security zones • Vibrating alert. • 16 notifications ringtones. • OLED-display. • Vibration confirmation of the button press. • Battery level indicator. • Current time indication. • Time synchronizes with the base unit for exact time stamp in the event history. • Engine* and interior temperature, voltage and fuel level indication. • Prompt remote access to the settings of shock/tilt/motion sensor.
  • Page 8 • Advanced processing of sensor data, eliminating false alarm possibilities. • Precision measurement of interior and engine* temperature, displayed on the remote. • Two-step unlocking of the doors. • Arming when the engine is running. • Automatic arming. • Delay for interior lighting when arming. • Software updates via built-in micro-USB socket. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 9: System Set

    S Y S T E M F E T U R E S Car security zones Pandora LIGHT PRO service-security system guards following independent zones with corresponding zone notifications on the remote and recording alarms into the event history: • car doors perimeter (separate for every door*);...

  • Page 10: Remote Controls

    3 seconds will cause the remote to switch off. WARNING! All control commands are transmitted via radio channel, for maximum effectiveness and range it is recommended not to shield aerial area (see picture) with fingers when using a remote control PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 11: Led Indicator Signals

    R E M O T E C O N T R O L Button 2 Button 3 Button 1 Aerial 12 0B OLED- display SEND/ALARM indicator LED INDICATOR SIGNALS Green indicator: • Flashes if there is a connection with the base unit • Goes dark when there is no connection with the base unit. Red indicator: • Flashes frequently if there is any notification • Flashes occasionally when there is no connection. WARNING! A remote control is a unifi ed control device.

  • Page 12: Quick Access Functions Of The Main Control Remote

    Disarming with sound Unlock doors Unlock doors confirmation (short press) Disarming without Unlock doors sound confirmation (1 sec.) Switch off the ignition Switch off «Ignition during remote or maintenance» mode automatic engine start (> 2 sec) procedure. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...
  • Page 13 R E M O T E C O N T R O L Switch on LCD lighting (available only on the remote with LCD) (short press) (1 sec.) Unlock trunk (CH1) Switch on/off timer channel (CH2) (2 sec.) (3 sec.) Switch on/off remote (available only on the remote with LCD) PANIC mode (short press)

  • Page 14: Icons Of The Remote Control

    Numeric indicator displays current Tilt sensor time Security zone Motion sensor 12.0V security zone Battery voltage Doors security zone 12° Interior Front hood temperature security zone 0° Trunk Engine Security zone temperature* Ignition Fuel level* Security zone PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 15: Arming Procedure

    R E M O T E C O N T R O L Handbrake/ neutral Engine operation indicator, Brake icon pedal security zone Low voltage Engine is stopped security zone STOP * Separate display indication of doors, original alarm status, fuel level depend on information in CAN-bus digital protocol of specific car ARMING PROCEDURE Arming the system allows monitoring of all security zones, locks the doors and blocks...

  • Page 16: Disarming Procedure

    4 times and turn signals will flash 4 times, the remote control will sound «WARNING!» ringtone (after «DISARMING» ringtone) and will indicate zones triggered. All recent alarm events can be viewed in the event history. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 17: Emergency Disarming

    R E M O T E C O N T R O L CONTROL OVER THE SYSTEM IN A CASE OF EMERGENCY In case you cannot disarm the system using the remote control or radio tag, the «Secret PIN-code» located on the owner’s plastic card can be used.
  • Page 18 After correct input of PIN-code the system will enter programming mode if it was disarmed and the ignition was switched off. For emergency arming when the engine is stopped, press and hold VALET button for 3 seconds. The system will be armed in 30 seconds. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 19: Enabling/Disabling An Immobilizer Radio Tag

    R E M O T E C O N T R O L ENAbLING/DISAbLING AN IMMObILIzER RADIO TAG Write down or remember the «Service PIN-code» To enable/disable a radio tag, enter level 15 (the system should be in programming mode). Enter the «Secret PIN-code» to disable radio tag or press VALET button once to enable radio tag.

  • Page 20: Unlocking The Trunk Lock

    If the trunk was not opened in 15 seconds after using «unlock trunk» command, the system will lock it again, enable sensors and arm trunk security zone. This will be indicated with 1 flash of turn signals. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 21: Locking/Unlocking Doors When Ignition Is Being Switched On

    R E M O T E C O N T R O L LOCKING/UNLOCKING DOORS WHEN IGNITION IS bEING SWITCHED ON The system controls doors locking when the engine is running. To lock doors, shortly press arming button, to unlock doors, press disarming.

  • Page 22: Car Search Function

    To activate this mode without sound confirmation, press and hold both buttons for 1 second until the sound and vibration signal. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 23: Panic Mode

    R E M O T E C O N T R O L short press 1 ash 30 sec. press and Doors locking, hold for 1 sec. system arming 1 ash 1 ash To cancel delayed arming when it is triggered, simply press button.

  • Page 24: Programmed Neutral Procedure (For Cars With Manual Transmission)

    The engine operation icon will be spinning on LCD remote and security mode status icon will light. 5. The engine will be stopped. Now the system is ready to perform remote and automatic engine start. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 25: Remote Engine Start

    R E M O T E C O N T R O L xate the car using a handbrake leave the car, close the doors in 3 sec., the engine will be stopped, «engine stop» ringtone the system is ready to perform remote start short press...
  • Page 26 «engine stop in 1 minute» ringtone will play every 10 seconds. Sending «Remote engine start» command will extend its operation period by 10 minutes. This procedure can be repeated multiple times. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 27: System Settings Menu

    siren R E M O T E C O N T R O L settings SYSTEM SETTINGS MENU Enter the main menu with button short press. To switch between menu sections siren shortly press button. settings 12 48 entering settings menu remote start settings sounds...
  • Page 28 To exit menu, press and hold button 14 45 for 1 second. • Maintenance mode of the car valet mode disabled 06 30 * The function is not available in this model valet mode enabled PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 29: Engine Preheater

    TIMER CHANNELS Timer channels can be used to implement additional functions and to control external devices. Timer channels can be adjusted via Pandora AlarmStudio. «TIMER CHANNELS MENU» To enter , shortly press button. The following presses of button will cause switching between channels.
  • Page 30 4 enabled channel 4 channel 4 disabled enabled enabled disabled channel 1 channel 1 enabled channel 1 enabled channel 1 enabled channel 1 enabled enabled channel 2 PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM channel 2 enabled channel 2 enabled...

  • Page 31: Car Status Control

    R E M O T E C O N T R O L system CAR STATUS CONTROL CHECK controls To receive information about engine, interior temperature, battery voltage and fuel «SYSTEM CONTROLS» level, select menu and shortly press button. 12 0V 24°...

  • Page 32: Automatic Engine Start Settings

    NOTE: Engine start via temperature is available only if temperature sensor is connected. The sensor availability depends on the system set. WARNING! Enable remote start if your local legislations allows driverless cars to have working engine. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...
  • Page 33 remote start remote start start R E M O T E C O N T R O L start settings remote start settings by time by time settings enabled enabled remote start start start remote start settings by time start start start by time...
  • Page 34 80° stop temp 80° 80° PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 35: Sensors Settings

    R E M O T E C O N T R O L SENSORS SETTINGS The system allows to adjust shock/motion/tilt sensors using the remote control. «SENSOR SETTINGS» Shortly press button to enter menu. Shortly press button to switch between menu sublevels of the shock/motion/tilt sensors. The sensitivity of a sensor are increased using button and decreased using button.
  • Page 36 = датчик удара тревож. уров. включен тревож. уров. включен включен доп. датчик increase decrease adjusting датчик удара shock sensor PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM датчик удара предвар. уров. warn. lvl. = датчик удара предвар. уров. включен предвар. уров.

  • Page 37: Motion Sensor Settings

    движение R E M O T E C O N T R O L MOTION SENSOR SETTINGS регулировка «MOTION SENSOR For prompt remote adjusting of motion sensor, select датчика движ. ADJUSTMENT» submenu by short presses of button. The sensor sensitivity can be set with short presses of buttons.

  • Page 38: Wiring Diagram

    Pandora LIGHT PRO For remote engine start Black IMMO-KEY2/INP7 8 16 White IMMO-KEY1/INP1 Green Trunk trigger Button VALET indicator, VALET button Engine temperature sensor Engine preheater control micro- Webasto Sockets Thermotop Evo, Eberspaecher Hydronic/ LIN out Hidronic 2 LIN connection...
  • Page 39 + 12V WARNING! Before starting the installation of the system, select a car model in ALARMSTUDIO (CAN-bus protocol) Ignition Brown (–) Starter CH10 Relay Yellow (–) module / Brake Pedal* (wiring Orange (–) diagram is on Bypass the next page, the module Green (–)
  • Page 40 Bypass CH8*** Green (–) NO blocking/ NC blocking Blue (–) Relay CH7*** module For remote start implementation via Start/Stop button Blue Blue/Black ** Total current of relays R3+R4+R5 should not exceed 40 Green *** For PANDORA LIGHT PRO systems Green/Black...

  • Page 41: Wiring Description

    W I R I N G D E S C R I P T I O N • W I R I N G D I A G R A M WIRING DESCRIPTION Х4 Main Socket •...
  • Page 42 2A). This output is multipurpose, it can operate in accordance with selected logic. Wire «16» (Red) («Power supply» +12V) • — It should be connected to reliable conductor with constant voltage of 12V. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...
  • Page 43 W I R I N G D E S C R I P T I O N • W I R I N G D I A G R A M Х5 socket (Relay module) Wire «1» (Blue) (CH7) •...
  • Page 44 Wire «3» (Black) (INP7-/IMMO-KEY2) • — Factory setting is «Trunk trigger». This wire connects to appropriate wire that becomes grounded when a trunk opens. This input is multipurpose, it can operate in accordance with selected logic. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 45: Siren Signal Settings

    R E M O T E C O N T R O L SIREN SIGNAL SETTINGS «SIREN SETTINGS» To configure siren sounds, select menu. Select one of the siren sound options using button. To save new settings, shortly press button. siren all sound signals are settings...

  • Page 46: Sound Notification Settings

    There are 3 options to notify when the owner is not in radio coverage zone. Select sounds «CONNECTION LOST» menu, short presses of button will cause switching between menu settings. This mode does not require to save. siren sounds PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 47: Maintenance Mode

    R E M O T E C O N T R O L connect. lost: connect. lost: connect. lost: ringtone ringtone ringtone «Connection lost» ringtone notification connect. lost: connect. lost: connect. lost: alarm alarm alarm signal alarm connect. lost: connect. lost: connect.

  • Page 48: Time Settings

    14 45 hours minutes This mode does not require to save 06 30 To exit menu, press and hold button for 1 second. WARNING! Enable bluetooth function on your mobile device to use Pandora bT application. PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 49: Alarm Settings

    alarm clock будильник R E M O T E C O N T R O L выключен ALARM CLOCK SETTINGS alarm clock alarm clock disabled «ALARM CLOCK» To set up the alarm clock, select menu. Enable alarm with short будильник press of button or disable it with short press of button.

  • Page 50: Immobilizer

    If indicator does not flash or light, the tag battery (see «Replacing immobilizer tag battery» section). should be replaced PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 51: Arming/Disarming In Hands Free Mode

    CAN-bus or by analog inputs. When arming and disarming original security system, Pandora will be armed and disarmed respectively. The presence of a tag in the radio zone is not required, but at the beginning of motion if the tag is not detected by the system, the engine will be blocked.

  • Page 52: Anti-Hi-Jack Mode

    I M M O B I L I Z E R ANTI-HI-JACK MODE This mode is disabled by default. Use Pandora AlarmStudio to enable this mode. Anti-hijack mode helps to prevent aggressive seizure of the car using delayed engine blocking on door opening.

  • Page 53: Replacing Immobilizer Tag Battery

    I M M O B I L I Z E R REPLACING IMMObILIzER TAG bATTARY Carefully open the cover of the tag’s battery compartment. Extract Open here discharged battery and insert a new one keeping in mind the correct polarity. Replacing a battery will not cause a loss of tag code information, as authorization data is stored in the non-volatile memory of the MCU.

  • Page 54: Pandora Bt Mobile Application

    After installing the application, perform the mobile device registration procedure «REGISTRATION AND DELETING A MOBILE DEVICE» (see p. 66) The application usage The system should be in the Bluetooth radio coverage zone. Start Pandora BT, the application will automatically find the system and make a connection; after that the main menu of the application will open. «CONTROL»...

  • Page 55: System Configuration And Programming

    P R O G R A M M I N G T H E S Y S T E M PROGRAMMING THE SYSTEM ENTERING PROGRAMMING MENU VALET To change the system settings or program the system using a computer or button, the system should be in programming mode.
  • Page 56 Status indicator lights during PIN-code entering: Short orange flash Confirmation of VALET button pressing Short red flash Confirmation of entering a PIN-code digit Red and green flashes PIN-code is correct Long red flash PIN-code is incorrect PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 57: Preparing To Program The System Using A Computer

    USB cable, a computer with Windows XP/Vista/7/8/10 and AlarmStudio application. It is required to create an account in AlarmStudio to use Pandora CLONE for remote engine start (you can register without a connection to a system). Pandora CLONE procedure requires Internet connection.

  • Page 58: Programming Using Valet Button

    Reserved Level 10 Configuring system settings via the wireless interface Level 11 Programming and configuring «Immobilizer code» Level 12 Calibrating of fuel level Level 13, 14 Reserved Level 15 Emergency disabling of immobilizer radio tag PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...
  • Page 59 P R O G R A M M I N G T H E S Y S T E M Level 16 Updating bluetooth modem firmware Level 17 Programming bypass original immobilizer Level 18 Registering and unregistering mobile device Level 19, 20 Updating radio relays №1, №2 firmware Level 21 Updating RHM-03 bT firmware...
  • Page 60 «Smart Turbo Timer», it is necessary to record the engine idle speed. To record idle speed to the non-volatile system memory, enter the programming VALET menu. Press button three times. Switch on the ignition and start the engine PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...
  • Page 61 P R O G R A M M I N G T H E S Y S T E M after entering this level of programming (the engine should be warmed-up, idle speed should match the stable idle speed of the warmed-up engine). The system will confirm the presence of the idle speed status with green flashes of indicator.
  • Page 62 Level 10 – Configuring system settings via the wireless interface This function is under construction. Level 11 – Programming and configuring «Immobilizer code» VALET To program the «Immobilizer code», enter the programming mode and press button 11 times. The level is divided into 3 sublevels (Sublevel 11.1 – Selecting buttons; sublevel 11.2 entering PIN-code; sublevel 11.3 – confirmation of the PIN-code input). PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...
  • Page 63 P R O G R A M M I N G T H E S Y S T E M The system will automatically enter the sublevel 11.1 (Selecting buttons) after entering the level 11. The system can determine buttons via analog «Code immobilizer»...
  • Page 64 (press the button a number of times equals to the inputting digit; pauses between presses should not exceed 1 second). VALET Run the engine no less than in 1 minute, then press button – the data will be sent to the base unit. To save, press button, pressing of button will be PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...
  • Page 65 P R O G R A M M I N G T H E S Y S T E M canceled the calibration. VALET To exit the programming mode, enter sublevel 12 or press button more than 12 times. To reset all calibration values, proceed to sublevel 11 (do not switch on the ignition).
  • Page 66 Level 16 – Updating built-in Bluetooth modem firmware* Download the firmware from www.tssgroup.sk and install Pandora BT or Pandect BT application on your mobile device. To update firmware of the built-in Bluetooth modem, enter programming mode...
  • Page 67 P R O G R A M M I N G T H E S Y S T E M short sound signal and indicator will light green. If the learning procedure finishes with an error, indicator will light red and a siren will emit four sound signals. Saving changes: VALET To finish the learning procedure, switch off the ignition and press...
  • Page 68 Level 19, 20, 21, 22, 25, 26 – Updating firmware of additional devices Download the firmware from www.tssgroup.sk and install Pandora BT application on your mobile device.

  • Page 69: Additional Devices

    P R O G R A M M I N G T H E S Y S T E M ADDITIONAL DEVICES Blocking BTR-101 radio relay is optionally available for Pandora LIGHT PRO. Blocking radio relay with built-in accelerometer should be placed in the engine compartment.

  • Page 70: Siren Sounds And Turn Light Signals

    «Sensors triggered»signal when 4 sound / 4 light signals disarming «Sensor malfunction» signal when 4 sound / 4 light signals arming Sensor warning level triggered 3 sound signals Car search 5 sound / 5 light signals PANDORA LIGHT PRO SERVICE-SECURITY SYSTEM...

  • Page 71: Meaning Of Led Indicator Colors

    A D D I T I O N A L I N F O R M A T I O N MEANING OF LED INDICATOR COLORS Indicator status Meaning Short red flashes The system is armed Lit red The system is preparing for automatic arming Orange flash Confirms VALET button press Orange flashes...
