Seagull Models Grumman F8F Bearcat Assembly Manual page 20

GRUMMAN F8F BEARCAT
2.
3.
M5x25mm and washers.
Attach the motor to the front of the elec-
tric motor box using four 4mm blind nut,
four M4x25mm hex head bolts to secure
the motor. Please see picture shown.
4.
5.
20
4mm.
Instruction Manual.
hen, use 5.5mm drill bit to enlarge the
holes on the electric motor box.
6.
5.5mm
7.
Blind nut.
5) Attach the motor to the front of the
electric motor box using four 4mm blind
nut, four M4x20mm hex head bolts to se-
cure the motor. Please see picture shown.
8.
M4x20mm.
