Depending upon the brand of your computer, you may or may
not wish to select this option when printing. For most
computers, selecting this option will enhance the rasterizing
and printing process. In this case, the
option should be selected. For some computers, however, this
option may not be supported by the particular brand of PC and
should not be selected.
Use 32-bit Spooler
Select this option for consistently faster print processing under
Windows 95/98/Me. This option is only selectable if operating
under Windows 95/98/Me and if the included 32-Bit Print
Spooler software has been installed. When selected, this option
allows the printer driver to send all print jobs to the 32-Bit
Print Spooler rather than to the Windows system print spooler.
See Part C of this section for complete details on the 32-Bit
Print Spooler. This option and the 32-Bit Print Spooler software
will not function in Windows 2000/XP .

Calibrate Tab

Select the Calibrate tab to display options for fine-tuning the
position of your printed image and to adjust the non-printing
center size on a disc.
IMPORTANT! The Image Placement values labeled on your printer's rear
To adjust the horizontal and vertical position, click on the
adjust arrows to select the number of pixels up-and-down
(vertical) or side-to-side (horizontal) you would like your
image to move when printed. As a rule, adjusting your image
12 pixels will move it exactly 1 millimeter. Increasing the
vertical calibration (clicking the up arrow) will move the image
on the disk toward the back of the Optical Disc Printer.
Increasing the horizontal calibration (clicking the left arrow)
will move the image on the disk toward the left side of of the
Optical Disc Printer as you face the printer. Once you have
entered the optimum calibration values with the best
alignment, you will most likely not need to change them again.
22 Using the Optical Disc Printer with Windows
panel must be entered into the Vertical and Horizontal boxes
prior to printing. These values have been optimized
specifically for your printer during final assembly and allow
images to be centered on a CD when printed.
INDEX
Write Direct to Port
