4. Confirm that the end of the
plastic front panel labeled "Optical Disc Printer" is closest
to you. This is the Supply End. The other end is the Take-
Up End.
5. Lift up the front Ribbon Hold-Down Bracket.
Supply End
6. Lift up the rear Ribbon Hold-Down Bracket by pulling the
bracket up and pressing backwards, exerting extra pressure
on the side with the gear. You will notice that the shaft of
the Ribbon Hold-Down Bracket is slotted on the gear side.
Make certain that you press toward the back of this slot in
order to lift the Hold-Down Bracket properly. DO NOT
FORCE THE BRACKET OPEN.
INDEX
Ribbon Cartridge
Take-up End
Ink Ribbons and Optical Media 7
with the
Gear Side
