PRODUCT STRUCTURE DIAGRAM
Cooling Vents
Bowens Mount
COB Light Chip
T-Handle /
Baby Pin Mounting Screw
Menu button
Mode button
Display screen
Knob 1:
Brightness adjustment /
Selection confirmation
power button
Power input connector
5
Rosette angle
locking handle
Yoke
Baby Pin Receiver/
Mounting Column
Return button
Cooling button
Knob 2:
Parameter adjustment
DMX output connector
DMX input connector
