Wireless antenna
Description
Wireless antenna (includes main and auxiliary wireless antenna cables, transceivers, and double-
sided adhesive)
Before removing the wireless antenna, follow these steps:
1.
Shut down the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2.
Disconnect all external devices connected to the tablet.
3.
Disconnect the power from the tablet by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
4.
Remove the display panel assembly (see
Remove the wireless antenna:
1.
Disconnect the wireless antenna cables from the WLAN terminals on the system board.
NOTE:
antenna cable connects to the WLAN module "#2/Aux" terminal.
2.
Detach the wireless antenna auxiliary transceiver (2) from the back cover. (The wireless antenna auxiliary
transceiver is attached to the back cover with double-sided adhesive.)
3.
Detach the wireless antenna main transceiver (3) from the back cover. (The wireless antenna main
transceiver is attached to the back cover with double-sided adhesive.)
4.
Release the wireless antenna main cable from the retention clips (4) built into the back cover.
40
Chapter 5 Removal and replacement procedures
The #1 WLAN antenna cable connects to the WLAN module "#1/Main" terminal. The #2 WLAN
Display panel assembly on page
Spare part number
L03255-001
30).
