The following pinout is valid on the target side:
Signal Signal Description
Direction
I Reference Voltage
Ground
Ground
Not Connected
Ground
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware failure.
Signal Pin Pin
Vref 1 2
GND 3 4
GND 5 6
NC 7 8
GND 9 10
10-pin Infineon DAP pinout
Signal Signal Description
DAP1 DAP Data pin
DAP0 DAP clock
DAP2 Optional 2nd DAP Data pin
DAP3 Optional 3rd DAP Data pin
nRESET Reset
Signal
Direction
I/O
O
I/O
I/O
I/O
