TASKING iSYSTEM Infineon SGBT HSTCU User Manual page 10

The following pinout is valid on the converter side:
Signal
Signal Description
Direction
Ground
I AGBT TX0_P
I AGBT TX0_N
Not Connected
I/O Target Reset Pin
I/O Optional 2nd DAP data
I/O Optional 3rd DAP data
O DAP Clock
Not Connected
Not Connected
Not Connected
Ground
Blue colored signals are trace signals.
The following pinout is valid on the target side:
Signal
Signal Direction
Description
I AGBT TX0_P
I AGBT TX0_N
Ground
Not Connected
Not Connected
Ground
Not Connected
Not Connected
Ground
Not Connected
Not Connected
Blue colored signals are trace signals.
*Current TriCore devices feature only one AGBT line while the Active Probe hardware is ready for
future devices with more AGBT lines.
Signal Pin
GND A1
TX0+ A2
TX0- A3
NC A4
nRESET A5
DAP2 A6
DAP3 A7
DAP0 A8
NC A9
NC A10
NC A11
GND A12
(HSTCU) USB-C pinout
Signal Pin
TX0+ 1
TX0- 3
GND 5
NC 7
NC 9
GND 11
NC 13
NC 15
GND 17
NC 19
NC 21
Revision A2: Samtec 22-pin ERF8 pinout
Pin Signal
B12 NC
B11 CLK+
B10 CLK-
B9 NC
B8 DAP1
B7 nTRST
B6 NC
B5 Vref
B4 NC
B3 NC
B2 NC
B1 GND
Pin Signal
2 Vref
4 DAP0
6 DAP1
8 NC
10 DAP2
12 nTRST/DAPEN
14 CLK+
16 CLK-
18 TGO
20 NC
22 nRESET
Signal Description
Not Connected
AGBT Clock
AGBT Clock
Not Connected
DAP Data
Output
Not Connected
Reference Voltage
Not Connected
Not Connected
Not Connected
Ground
Signal
Signal Direction
Description
Reference
Voltage
DAP Clock
DAP Data
Not Connected
Optional 2nd
DAP data
Output
AGBT Clock
AGBT Clock
AGBT Trigger
out
Not Connected
Reset
Signal
Direction
O
O
I
O
I
I
O
IO
I
O
O
O
I
IO
