AIR SPRING SERVICE
Mattoc / JUNIT Pro:
12
Install IRT cap into stanchion.
Torque to 200-220 LB-in [22.6-25
Nm] using standard cassette lock-
ring tool.
Mattoc Expert / Comp, JUnit 34
Expert, Circus Pro:
Install IVA cap into stanchion.
Torque to 200-220 LB-in [22.6-25
Nm] using a 24mm socket.
14
MATTOC / JUNIT 34 / CIRCUS 34 SERVICE GUIDE
AIR SPRING SERVICE
Mattoc / JUNIT Pro:
13
IRT to 100PSI.
NOTE: ALWAYS SET IRT PRESSURE
(TOP OF FORK) BEFORE DORADO
AIR PRESSURE (BOTTOM OF FORK)
Mattoc Expert / Comp, JUnit 34
Expert, Circus Pro:
Skip to step 14.
14
main air chamber to 30 PSI. This
will aid in installing the casting
later.
MATTOC / JUNIT 34 / CIRCUS 34 SERVICE GUIDE
