Address Setting - ACME PIXEL LINE IP User Manual

If you use a universal DMX controller to control the units, you have to set DMX address
between 1 and 512 so that the units can receive DMX signal.
Press the MENU button to access the control menus, select DMX Settings, press the ENTER
button to confirm. Use the UP/DOWN button to select DMX Address, press the ENTER
button to confirm, the present address will show on the display. Use the UP/DOWN button
to adjust the address between 001 and 512, press the ENTER button to store. To exit the
menu, press MENU, or wait 30 seconds.
Please refer to the following diagram to address your DMX512 channel for the first 4 units.
Channel Mode
7 channels
15 channels
21 channels
39 channels
112 channels
17 channels
33 channels
65 channels
68 channels
117 channels
70 channels

6.2 Address Setting

Unit 1 Unit 2
Address Address
1
1
1
1
1
1
1
1
1
1
1
- 30 -
Unit 3
Address
8 15
16 31
22 43
40 79
113 225
18 35
34 67
66 131
69 137
118 235
71 141
Unit 4
Address
22
46
64
118
337
52
100
196
205
352
211
