ACME PIXEL LINE IP User Manual page 18

DMX Settings
Enter the control menu and select DMX Settings, press ENTER. Use the UP/DOWN button
to select DMX Address, Channel Mode, No DMX Status, View DMX Value, Connect Option,
Network, Art-Net Settings or sACN Settings.
DMX Address
Channel Mode
Select DMX Address, press ENTER.
Use UP/DOWN button to select an address, confirm your selection with
ENTER.
CHANNEL MODE
7 CH
15 CH
21 CH
39 CH
112 CH
17 CH
33 CH
65 CH
68 CH
117 CH
70 CH
To exit the menu, press MENU, or wait 30 seconds.
Select Channel Mode, press ENTER.
Use UP/DOWN button to select between 7 CH, 15 CH, 21 CH, 39 CH,
112 CH, 17 CH, 33 CH, 65 CH, 68 CH, 117 CH and 70 CH, confirm your
selection with ENTER.
To exit the menu, press MENU, or wait 30 seconds.
- 17 -
DMX ADDRESS
1-506
1-498
1-492
1-474
1-401
1-496
1-480
1-448
1-445
1-396
1-443
