- Page 1 审核 2018.06.25 受控正本 LP-F1000 CW LP-F1000 WW User Manual Please read the instruc on carefully before use...
-
Page 2: Table Of Contents
CONTENTS 1. Safety Introductions ....................2 2. Technical Specifications ..................3 3. How To Set The Fixture ..................4 3.1 Control Panel ....................4 3. 2 The Plate for Barn Door Installation ............... 5 4. How To Control The Unit ..................10 4.1 Master/Slave Function .................. -
Page 3: Safety Introductions
1. Safety Introductions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. ... -
Page 4: Technical Specifications
2. Technical Specifications Power Voltage: AC 100 ~ 240V, 50/60Hz Power Consumption: 100W Light Sources: 240 pcs CW LED (LP-F1000 CW) 240 pcs WW LED (LP-F1000 WW) Color Temperature: 3200±150K 5600±250K Beam Angle： 130°... -
Page 5: How To Set The Fixture
3. How To Set The Fixture 3.1 Control Panel 4 5 6 7 8 1. Display: Shows the various menus and the selected functions. 2. Button: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions... -
Page 6: The Plate For Barn Door Installation
Connect with the multimedia and use software to control the units via ArtNet; 3. 2 The Plate for Barn Door Installation At first, please push the barn door by hand. Screw Secondly, please put the Barn Door into the unit, to fasten the screws of the slot, then finish the barn door installation. - Page 7 DMX Address IP Address DMX Setting rt-Net Setup Sub-Net Universe 1 CH Channel Mode 3 CH Favt Dimmer Speed Smooth Linear Curve Square Law Curve Dimmer Curve Invert Square Law Curve S Curve Master Slave Mode Slave Master Slave Blackout DMX State Hold...
- Page 8 Contrast Ratio Backlight Auto Off Display Setting Invert Display Englivh Language Chinese Dimmer Manual Mode Fixture Time Firmware Version DMX Setting Select the DMX Setting, press the ENTER button to confirm. Use the UP and DOWN button to select DMX Address, Art-Net Setup or Channel Mode. DMX Address Select the DMX Address, press the ENTER button to confirm, the display will show the present address.
- Page 9 exit menu mode. Dimmer Speed Select the Dimmer Speed, press the ENTER button to confirm, use the UP and DOWN button to select the Fast or Smooth mode, press the ENTER button to store. Press the MENU button back to the last menu or idling 30 seconds to exit menu mode.
- Page 10 the last menu or idling 30 seconds to exit menu mode. DMX State Select DMX State, press the ENTER button to confirm, the present mode will blink on the display, use the UP and DOWN button to select Master Slave, Blackout or Hold, press the ENTER button to store.
-
Page 11: How To Control The Unit
Language Select Language, press the ENTER button to confirm, the present mode will blink on the display, use the UP and DOWN button to select Chinese or English, press the ENTER button to store. Press the MENU button back to the last menu or idling 30 seconds to exit menu mode. Manual Mode Select Manual Mode, press the ENTER button to confirm, the present mode will blink on the display, use the UP and DOWN button to select the Dimmer, press the ENTER button and use the... -
Page 12: Master/Slave Function
2. By DMX controller 3. By multimedia software via ArtNet No need to turn the unit off when you change the DMX address, as new DMX address setting will be affected at once. 4.1 Master/Slave Function By linking the units in master/slave connection, the first unit will be master automatically. You should set the master unit effect via its knobs, then the other units (slave) will lighting as the same. -
Page 13: Dmx512 Configuration
4.3. DMX512 Configuration 1 Channel Mode: CHANNEL VALUE FUNCTIONS DIMMER 000 ~ 255 0 100% 2A Channel Mode: CHANNEL VALUE FUNCTIONS DIMMER 000 ~ 255 0 100% STROBE 000-031 032-063 064-095 Strobe: Slow Fast 096-127 128-159 Strobe Pulse: Fast Slow 160-191 192-223 Random Strobe... -
Page 14: Dmx512 Connections
096-127 128-159 Strobe Pulse: Fast Slow 160-191 192-223 Random Strobe 224-255 4.4. DMX512 Connections The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. 1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit. -
Page 15: Troubleshooting
5. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The fixture does not work, no light 1. Check the connection of power and main fuse. 2. Measure the mains voltage on the main connector. B. - Page 16 Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1: 2009+A1:2012; EN55103-2: 2009; EN61000-3-2: 2014; EN61000-3-3: 2013. & Harmonized Standard EN 60598-1:2015;...
