Icom GM600 Instruction Manual page 9

q DISTRESS KEY [DISTRESS] (p. 35)
Hold down for 3 seconds to transmit a Distress call.
w ENTER KEY [ENT]
Push to set the entered data, selected item, and so on.
e LEFT AND RIGHT KEYS [Ω]/[≈]
➥ Push to scroll the Software Key functions. (p. 5)
➥ In the character or number entry mode, push to select
the desired character or number in the keypad.
(p. 18)
r UP AND DOWN/CHANNEL SELECT KEYS [∫]/[√]
➥ Push to select the operating channel (p. 13), Menu
items (p. 12), Menu settings (p. 12), and so on.
➥ While scanning, push to check the Favorite channels,
change the scanning direction or manually resume a
scan. (p. 27)
t KEYPAD
Push to enter numbers, letters or symbols.
For channel number entry, see page 13.
For channel name entry, see page 18.
y POWER KEY [ ]
Hold down for 1 second to turn the transceiver ON or
OFF.
PANEL DESCRIPTION
u CHANNEL 16/CALL CHANNEL KEY [16/C]
➥ Push to select Channel 16. (p. 13)
➥ Hold down for 1 second to select the Call channel.
(p. 13)
• "CALL" is displayed when the Call channel is selected.
i VOLUME/SQUELCH DIAL [VOL/SQL] (p. 15)
➥ Rotate to adjust the volume level.
➥ Push once or twice to display the Volume or Squelch
Setting screen, and then rotate to adjust the volume or
squelch level.
o CLEAR KEY [CLR]
Push to cancel the entered data, or to return to the
previous screen.
!0 CHANNEL SELECTOR/ENTER SWITCH [CH/ENT]
➥ Rotate to select the operating channel (p. 13),
Menu items (p. 12), Menu settings (p. 12), and
so on.
➥ Push to set the entered data, selected item, and so
on. (p. 12)
!1 MENU KEY [MENU]
Push to enter or exit the Menu screen. (p. 12)
2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
3
