Yamaha MIO Service Manual page 33

Item
Bulbs (voltage/wattage × quantity)
Headlight
Tail/brake light
Front turn signal light
Rear turn signal light
Meter light
Indicator light
(voltage/wattage × quantity)
Turn signal indicator light
High beam indicator light
Electric starting system
System type
Starter motor
Model/manufacturer
Power output
Armature coil resistance
Brushes
Overall length
Spring force
Commutator diameter
Mica undercut
Starter relay
Model/manufacturer
Amperage
Coil resistance
Horn
Horn type
Model/manufacturer × quantity
Max. amperage
Performance
Coil resistance
Turn signal relay
Relay type
Model/manufacturer
Self-cancelling device built-in
Turn signal blinking frequency
Wattage
Fuel gauge
Model/manufacturer
Sender unit resistance- full
Sender unit resistance- empty
ELECTRICAL SPECIFICATIONS
12 V 32 W/32 W × 1
12 V 5 W/21 W × 1
12 V 10 W × 2
12 V 10 W × 2
12 V 1.7 W × 1
12 V 1.7 W × 1
12 V 1.7 W × 1
Constant mesh
5TL/PT. MORIC
0.25 kW
0.032 ~ 0.039 Ω at 20 °C (68 °F)
9.5 mm (0.37 in)
5.52 ~ 8.28 N
(563 ~ 844 gf, 19.87 ~ 29.80 oz)
22 mm (0.87 in)
1.5 mm (0.06 in)
5TN/OMRON
50 A
54 ~ 66 Ω at 20 °C (68 °F)
Plane
3WE/PT. MORIC × 1
1.5 A
95 ~ 105 dB/2 m
4.30 ~ 4.80 Ω
Condenser
FR22-091/PT. MITSUBA
No
75 ~ 95 cycles/min.
10 W × 2 + 3.4 W
5TL/NIPPON SEIKI
4 ~ 10 Ω at 20 °C (68 °F)
90 ~ 100 Ω at 20 °C (68 °F)
2 - 13
Standard
SPEC
Limit
----
----
----
----
----
----
----
----
----
----
----
3.5 mm
(0.14 in)
----
21 mm
(0.83 in)
----
----
----
----
----
----
----
----
----
----
----
----
----
----
----
----
----
