Yamaha MIO Service Manual page 31

Item
Front suspension
Suspension type
Front fork type
Front fork travel
Spring
Free length
Installed length
Spring rate (K1)
Spring rate (K2)
Spring stroke (K1)
Spring stroke (K2)
Optional spring available
Fork oil
Recommended oil
Quantity (each front fork leg)
Level (from the top of the inner
tube, with the inner tube fully com-
pressed, and without the fork
spring)
Inner tube outer diameter
Inner tube bend limit
Rear suspension
Suspension type
Spring/shock absorber type
Rear shock absorber assembly travel 78 mm (3.07 in)
Spring
Free length
Installed length
Spring rate (K1)
Spring rate (K2)
Spring stroke (K1)
Spring stroke (K2)
Optional spring available
CHASSIS SPECIFICATIONS
Standard
Telescopic fork
Coil spring/oil damper
90 mm (3.54 in)
266.7 mm (10.50 in)
256.7 mm (10.11 in)
3.90 N/mm (0.40 kgf/mm, 22.27 lb/in)
7.10 N/mm (0.72 kgf/mm, 40.54 lb/in)
0 ~ 50 mm (0 ~ 1.97 in)
50 ~ 90 mm (1.97 ~ 3.54 in)
No
Fork oil 10 W or equivalent
3
57 cm (2.01 Imp oz, 1.93 US oz)
88 mm (3.46 in)
26 mm (1.02 in)
----
Unit swing
Coil spring/oil damper
249.6 mm (9.83 in)
245.6 mm (9.67 in)
28.5 N/mm (2.91 kgf/mm, 162.74 lb/in)
40.0 N/mm (4.08 kgf/mm, 228.40 lb/in)
0 ~ 50 mm (0 ~1.97 in)
50 ~ 78 mm (1.97 ~ 3.07 in)
No
2 - 11
SPEC
Limit
----
----
----
261.4 mm
(10.29 in)
----
----
----
----
----
----
----
----
----
----
0.2 mm
(0.008 in)
----
----
----
244.6 mm
(9.63 in)
----
----
----
----
----
----
