Yamaha MIO Service Manual page 30

Item
Rear tire
Tire type
Size
Manufacturer/model
Tire pressure (cold tire)
0 ~ 90 kg
Min. tire tread depth
Front brake
Brake type
Operation
Brake lever free play (at lever end)
Brake discs
Diameter × thickness
Min. thickness
Max. deflection
Brake pad lining thickness-inner
Brake pad lining thickness-outer
Master cylinder inside diameter
Caliper cylinder inside diameter
Recommended fluid
Rear brake
Brake type
Drum brake type
Brake lever free play (at lever end)
Drum inside diameter
Lining thickness
Shoe spring free length
(camshaft side)
Shoe spring free length (pivot side)
Steering
Steering bearing type
Lock to lock angle (left)
Lock to lock angle (right)
CHASSIS SPECIFICATIONS
Standard
With tube
80/90-14M/C 40P
IRC/NR76
225 kPa (2.25 kgf/cm
----
Single-disc brake
Right-hand operation
0 mm (0 in)
200 × 3.5 mm (7.87 × 0.14 in)
----
----
5.3 mm (0.21 in)
5.3 mm (0.21 in)
11 mm (0.43 in)
33.34 mm (1.31 in)
DOT 4
Drum brake
Leading, trailing
10 ~ 20 mm (0.39 ~ 0.79 in)
130 mm (5.12 in)
4.0 mm (0.16 in)
52 mm (2.05 in)
48 mm (1.89 in)
Angular bearing
47.5°
47.5°
2 - 10
SPEC
2
, 33 psi)
Limit
----
----
----
----
0.8 mm
(0.031 in)
----
----
----
----
3.0 mm
(0.12 in)
0.15 mm
(0.006 in)
0.8 mm
(0.031 in)
0.8 mm
(0.031 in)
----
----
----
----
----
----
131 mm
(5.16 in)
2.0 mm
(0.079 in)
----
----
----
----
----
