Programming manual
3.2

The buttons

TEST
BUZZER
INVESTIGATE
SILENCE
RESET
EVACUATE
3.3

The LEDs

Description
ALARM
PRE-ALARM
DISABLED
TEST
NIGHT MODE
ON
The SmartLoop control panel
Initializes the test phase and acyivates all the control panel LEDs.
Silences the control panel buzzer. The buzzer will be enabled automatically if
another event occurs. RESET operations also silence the buzzer.
During Pre-alarm status, this button will activate a pre-set alarm delay.
If this button is pressed once, it will silence the NAC outputs, fault output
and all the 'Silenceable' outputs. If this button is pressed again (when the
LED is On), it will toggle (undo) the silence command.
Resets the control panel (clears alarms).
Activates the evacuation procedure. If this button is pressed by a member of
the public (Level 1- no access code or key required) during pre-alarm status,
it will generate an instant alarm.
If this button is pressed by a "User" or "Authorized User" (Level 2), it will
generate an instant alarm regardless of the system status.
STATUS group
Colour
Red The control panel is in alarm status. This LED goes On to signal
the following conditions:
- alarm status of a point defined as an "Alarm" point
- the evacuation phase is running (triggered by the EVACUATE
button on the control panel or on a connected repeater panel)
- the evacuation phase is running (triggered by the EVACUATE
button a Network control panel or on a Network repeater panel)
Red The control panel is in pre-alarm status. This LED goes On to
signal the alarm status of a point programmed as an "Alarm"
point with the "Pre-alarm" attribute.
Yellow If this LED is On, at least one of the system objects (point, zone,
output, communicator, etc.) has been disabled.
Yellow If this LED is On, at least one of the system objects (point, zone,
output, communicator, etc.) is in test status.
A zone test affects all the points of the zone concerned.
Yellow If this LED is On, the control panel is operating in night mode.
During Day mode, the control panel can generate pre-alarms and
hold silence status for an unlimited time. During Night mode, the
control panel can hold silence status for the pre-set time only.
During Night mode, the control panel cannot generate pre-alarms
as this function is disabled.
Green If this LED is On, the control panel is fully powered and operative.
If On solid:
