INIM SMARTLOOP 0051-CPR-0225 Manual page 11

Programming manual
Description
ACTIVE
FAULT
DISABLED
Description
ACTIVE
FAULT
DISABLED
The SmartLoop control panel
BELLS group
Colour If On solid:
Red If this LED is On (solid), at least
one of the 4 NAC outputs on the
control panel motherboard or
on the SmartLoop/INOUT
expansion board (programmed
to activate in the event alarm)
or NAC alarm output is active.
Yellow If this LED is On (solid), at least
one of the 4 NAC outputs on the
control panel motherboard or
on the SmartLoop/INOUT
expansion board (programmed
to activate in the event alarm)
or NAC alarm output is active.
Yellow If this LED is On (solid), at least
one of the 4 NAC outputs on the
control panel motherboard or
on the SmartLoop/INOUT
expansion board (programmed
to activate in the event alarm)
or NAC alarm output has been
disabled.
DIALLER group
Colour If On solid:
Red If this LED is On (solid), the
system is sending a
communication generated by
the SmartLoop/PSTN and/or
Smart/LAN telecom board
related to an alarm or fault
event.
Yellow If this LED is On (solid),
communication with the
SmartLoop/PSTN board is not
possible or a fault has been
detected on one of the two
telephone lines (L.E. or L.B.).
Yellow If this LED is On (solid), alarm
related telephone
communications generated by
the SmartLAN board and/or
fault related telephone calls
generated by the SmartLAN
board cannot be sent.
If blinking:
If this LED blinks, one of thee
above-mentioned events has
been cleared and saved to the
memory.
If blinking:
If this LED blinks, the system is
sending a communication
generated by the SmartLoop/
PSTN and/or Smart/LAN
telecom board that is not related
to an alarm or fault event.
If this LED blinks, a fault
relating to the SmartLoop/PSTN
board or telephone lines has
been cleared and saved to the
memory.
11
