2.4.2 Graphic conventions
Following are the graphic conventions used in the text. For the description of the text rules refer to Chapter
3 - The SmartLoop control panel and Chapter 4 - How to use the display and keypad.
Conventions
Text in Italics
<text>
[lowercase letter]
or [number]
BUTTON
Note:
The detached notes contain important information about the text.
Attention:
The attention prompts indicate that total or partial disregard of the procedure could damage
the connected devices.
Danger:
The danger warnings indicate that total or partial disregard of the procedure could injure the
operator or persons in the vicinity.
General information
Example
paragraph
Refer to
2.4.2 - Graphic
conventions
<CustomerCode>
[A] or [1]
Esc, RESET
Text in italics: indicates the title of a chapter, section, paragraph,
table or figure in this manual or other published reference.
Editable field
Representation of a part of the system or video object.
Computer or control panel keys.
Description
