2.7 Step 6: Verifying the Emulator Device Driver Installation

The emulator device driver enables the debugger to communicate with the
emulator. To ensure that the emulator driver is installed correctly, follow these
steps:
1) Turn off the power to the 'C2xx target board.
2) Connect the JTAG cable from your PC to the 'C2xx target board.
3) Turn on the power to the 'C2xx target board.
4) If a hard RESET is not generated automatically after power-up, apply a
5) From the command prompt in a MS-DOS
You should see a message similar to the following:
XDS510 IS RESET, HARDWARE VERSION 3
-
-

Troubleshooting

-
-
Step 6: Verifying the Emulator Device Driver Installation
hard RESET to the 'C2xx device.
emurst
If this message appears, you have correctly installed the emulator driver.
Turn to Section 2.8, Step 7: Verifying the Emulator and Debugger Installa-
tion .
If you see this message:
CANNOT DETECT TARGET POWER
follow the troubleshooting tips in the following section.
The target power is not on or the cables are not connected.
Be sure that power is applied to the target board and that the JTAG cable is
connected firmly.
The I/O switch settings on the XDS510-PC don't match the value specified
with the –p option.
If you are using nondefault I/O switch settings, you must specify the corre-
sponding –p option in either the D_OPTIONS environment variable or on
the command line when you invoke the debugger.
Installing the Emulator and C Source Debugger With MS-Windows
window, enter:
