Xds510-Pc Installation - Texas Instruments TMS320C2 Series Installation Manual

Step 1: Installing the XDS510-PC in Your PC
1) To minimize the risk of electric shock and fire hazard, be sure
2) To minimize the risk of personal injury, always turn off the
Setting the XDS510-PC into your PC
After you've prepared the XDS510-PC for installation, follow these steps.
1) Turn off the power to the PC, and unplug the power cord.
2) Remove the cover of your PC.
3) Remove the mounting bracket from an unused 16-bit slot.
4) Install the XDS510-PC in a 16-bit slot (see Figure 2–2).
5) Tighten down the mounting bracket.
6) Plug the target cable into the XDS510-PC (see Figure 2–3). The cable is
7) Replace the PC cover.
8) Plug in the power cord, and turn on the power to the PC.
Figure 2–2. XDS510-PC Installation
2-6
that all major components that you interface with Texas Instru-
ments devices are limited in energy and certified by one or
more of the following agencies: UV, CSA, VDE, or TUV.
power to your PC and unplug the power cord before installing
the XDS510-PC.
a 25-pin DSUB connector, shaped to ensure proper connection.
rear of computer
mounting bracket
XDS510-PC
16-bit slot
