iW-RainboW-G17D Linux User Guide

To create a directory and remove a directory from the mounted partition, execute below
commands respectively.
root@iWave-G17M/<mount_directory>$mkdir <directory_name>
root@iWave-G17M/<mount_directory>$rm –rf <target_directory>

To copy a file to the mounted partition, execute below command.
root@iWave-G17M/<mount_folder>$cp <soruce_file> <Destination>

To exit from the mount folder, execute below command.
root@iWave-G17M/<mount_directory>$cd /

To un mount the device, execute the below command.
root@iWave-G17M/~$umount <mount directory>

5.2 Network Devices Test

The iW-RainboW-G17M-Q7 platform will support the below network devices.

Ethernet

CAN
Testing device Requirements
To test the Network devices supported by iW-RainboW-G17M-Q7 platform, following Items are required

Ethernet connection

CAN cable

5.2.1 Ethernet Test


To check the IP address set, execute the below command.
root@iWave-G17M:~#ifconfig
eth0 Link encap:Ethernet HWaddr **:**:**:**:**:**
inet addr:********** Bcast:*********** Mask:255.255.255.0
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:28783 errors:0 dropped:87 overruns:0 frame:0
TX packets:15286 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:6218139 (5.9 MiB) TX bytes:4454482 (4.2 MiB)

If the IP address is not set, execute the below command.
root@iWave-G17M:~#udhcpc -i eth0
