7.3 Activating the on-board relay

While in a call with the intercom DTMF codes can be entered on the phone to trigger the
onboard relay of the intercom.
• Relay Pulse code
o Activates the relay for the configured Relay Pulse Duration.
• Relay Pulse Duration
o How long the relay will activate when the Pulse code is sent.
• Relay Activation Code
o This code activates the relay.
• Relay Deactivation Code
o This code deactivates the relay.
Note: Enable "Play Tone During DTMF Activation" if you want a tone to play when the
onboard relay is active.
Figure 7-5: Relay Settings
