Model number
NH2096-B
NH2096-M
NH2096-H
1.1.2. Power and safety requirements
The module draws up to 220 watts:
• Voltage: 100 VAC -240 VAC
• Current: 2.0 A - 1.0 A
• Frequency: 50 Hz - 60 Hz.
The module PSUs are compatible with international mains voltage

supplies.
1.1.3. Terminology
The nShield nShield 5c is referred to as the nShield nShield 5c, the Hardware Security
Module, or the HSM.

1.2. Handling an nShield nShield 5c

An nShield nShield 5c contains solid-state devices that can withstand normal handling.
However, do not drop the module or expose it to excessive vibration.
If you are installing the module in a 19" rack, make sure that you follow the nShield
nShield 5c Slide Rails Instructions provided with the rails. In particular, be careful of sharp
edges.
Only experienced personnel should handle or install an nShield nShield 5c. Always
consult your company health and safety policy before attempting to lift and carry the
module. Two competent persons are required if it is necessary to lift the module to a
level above head height (for example, during installation in a rack or when placing the
module on a high shelf).
1.2.1. Weight and Dimensions
Weight: 11.5kg
nShield® 5c Installation Guide
Used for
nShield nShield 5c Base
nShield nShield 5c Medium
nShield nShield 5c High
5 of 77
