- Page 1 nShield Security World nShield Trusted Verification Device v12.40 Installation Guide 04 March 2024...
-
Page 2: Table Of Contents
Contents Chapter 1: Introduction Chapter 2: Safety and security Chapter 3: Setting up the nShield Trusted Verification Device Connecting the metal support bracket Software installation Connecting an nShield TVD Disconnecting and reconnecting the nShield TVD Troubleshooting Chapter 4: Using the nShield Trusted Verification Device Chapter 5: Dimensions and operating temperatures Physical location considerations N-010030-X... -
Page 3: Chapter 1: Introduction
Chapter 1: Introduction ® The nShield Trusted Verification Device (TVD) is a USB connected smart card reader. The nShield TVD connects to a laptop or work station. The TVD facilitates the authentication between the smart card and the HSM. The user is prompted to confirm the Electronic Serial Number (ESN) of the HSM being displayed on the nShield TVD. -
Page 4: Chapter 2: Safety And Security
Chapter 2: Safety and security When the TVD is not being used it must be stored in a secure place. Note: There are no user-serviceable parts inside the nShield TVD. Any attempt to dismantle the nShield TVD results in any remaining warranty cover, the maintenance and support agreement, or both being rendered void. -
Page 5: Chapter 3: Setting Up The Nshield Trusted Verification Device
Chapter 3: Setting up the nShield Trusted Verification Device Connecting the metal support bracket Do the following: 1. Remove the nShield TVD and the metal stand from the packaging. 2. Slide the metal stand into the slots on either side of the TVD. 3. -
Page 6: Connecting An Nshield Tvd
Connecting an nShield TVD Do the following: 1. Connect the nShield TVD to your computer, using the USB cable. 2. If your operating system detects the nShield TVD automatically, allow it to finish. Figure 3. Connecting the nShield TVD to your computer Note: Do not connect a nShield TVD to your computer with a smart card already inserted. -
Page 7: Troubleshooting
Troubleshooting If the nShield TVD does not function as expected, disconnect the nShield TVD, wait a few seconds, and then reconnect it. If this does not solve your problem, contact nCipher Support at help.ncipher.com N-010030-X nShield® Trusted Verification Device Installation Guide... -
Page 8: Chapter 4: Using The Nshield Trusted Verification Device
Chapter 4: Using the nShield Trusted Verification Device Figure 4. The nShield TVD controls, card slot, and LED Item Description For inserting a smart card into the TVD, the chip on the card should face the user and A: Card slot inserted first into the card slot. -
Page 9: Chapter 5: Dimensions And Operating Temperatures
Chapter 5: Dimensions and operating temperatures Parameter Value Dimensions 62 (w) x 95 (h) x 14 (d) mm Weight Powered by USB host device 5V, 200 mA Operating temperature 0 – 50 °C Storage temperature -10 – 50 °C Operating and storage relative humidity Maximum 90% non-condensing Physical location considerations nCipher nShield HSMs are certified to NIST FIPS 140-2 level 2 and 3.
