Technical Specifications

5.6. Technical Specifications
Plastic, type PC (UL 94 V-0). Color: Light Grey. RAL 7035
Case Net dimensions (dxwxh): 90x106x58 mm / 3.5x4.2x2.3"
Recommended space for installation (dxwxh): 130x115x100 mm / 5.1x4.5x3.9"
Wall: M3 25mm (1") length screws. Secure mounting: below 2 meters (6 feet)
Mounting
DIN rail (recommended mounting) EN60715 TH35
Solid wires or stranded wires (twisted or with ferrule)
Per terminal:
Wires (for power
1 core: 0.5 to 2.5mm
supply and low-
2 cores: 0.5 to 1.5mm
voltage signals)
3 cores: not permitted
For distances longer than 3.05 meters (10 feet), use class 2 cables
1 x Green pluggable terminal block (3 poles)
12 to 36 VDC +/-10%, Max.: 250 mA
Power
24 VAC +/-10% 50-60 Hz, Max.: 127 mA
Recommended: 24 VDC
Ethernet 1 x Ethernet 10/100 Mbps RJ45
1 x Green pluggable terminal block (3 poles)
Port EIA 485 SGND (Reference ground or shield)
1500VDC isolation from other ports
Port KNX 1 x Orange pluggable terminal block (2 poles): A, B
AC-Port A (serial, 2 poles): Not used
AC Ports AC-Port B (serial, 3 poles): AC bus connection (XY)
AC-Port C: (serial, 3 poles): Not used
2 x Run (Power/Error)
2 x Port EIA-485 TX/RX
LEDs
2 x Port KNX TX/TR
1 x Button indicator
1 x Green pluggable terminal block (4 poles)
Binary inputs
I1, I2, I3, and Common
1500 VDC isolation from other ports
USB Mini-B type 2.0 compliant
Console port
1500 VDC isolation
2 x DIP switch blocks for EIA-485 serial port configuration:
Position 1:
On: 120 Ω termination active
SW A
Off: 120 Ω termination inactive
SW B
Position 2 and 3:
On: Polarization active
Off: Polarization inactive
Push button Refer to the user manual
Celsius: 0 .. 60°C
Operational
temperature
Fahrenheit: 32 .. 140ºF
Operational
5 to 95%. No condensation
humidity
Protection IP20 (IEC60529)
USER MANUAL Version 1.0.1
2
(24 to 11 AWG)
2
(24 to 15 AWG)
2 x Ethernet Link/Speed
2 x AC-Port A TX/RX
2 x AC-Port B TX/RX
2 x AC-Port C TX/RX
Midea commecial and VRF with KNX, Serial and IP support
