Connection

5.2.4. Connection Procedure for KNX

NOTE
Remember to check the
1. Connect the KNX TP communication cable to the gateway's KNX port.
IMPORTANT
Observe polarity.
2. Use the supplied USB Mini-B type to A type cable to connect the gateway, through its USB port, to a PC to
configure it with Intesis MAPS.
NOTE
You can use the Ethernet Port to connect the gateway and the PC instead.
NOTICE
Find all you need to know about the gateway configuration and Intesis MAPS in the
IN770AIR00xO000 Gateway configuration guide.
NOTICE
See the wiring diagram in the gateway connectors figure:
(page 10)
USER MANUAL Version 1.0.1
Common Connections (page
Midea commecial and VRF with KNX, Serial and IP support
12).
General view of all gateway connectors
Page 15 of 34
