5.5. Push Button

Find the push button at the top side, between the KNX and the Ethernet connectors.
See Figure Gateway layout (page 19)
NOTE
The button is hidden and only accessible using a thin object like a paper clip.
Common functionality:
Reset factory settings
1. Push the button.
2. Power on the gateway.
3. Wait four seconds.
4. Release the button.
Functionalities depending on the current project:
BACnet
• Push the button to send an I-Am message to all BACnet ports.
KNX
• Push the button to switch between normal mode and programming mode.
