Midea commecial and VRF with KNX, Serial and IP support
2. Use the supplied USB Mini-B type to A type cable to connect the gateway, through its USB port, to a PC to
configure it with Intesis MAPS.
NOTE
For Modbus RTU only, you can use the Ethernet Port to connect the gateway and the PC instead.
NOTICE
Find all you need to know about the gateway configuration and Intesis MAPS in the
IN770AIR00xO000 Gateway configuration guide.
NOTICE
See the wiring diagram in the gateway connectors figure:
(page 10)
Page 14 of 34
General view of all gateway connectors
USER MANUAL Version 1.0.1
Connection
