Integration into Home Automation Systems

6.4. Integration into Home Automation Systems

6.4.1. Home Automation Signals

The following tables list all available Home Automation signals for this gateway.
NOTE
• SET: Command used to control the indoor unit. It is sent by the client.
• CHN: Command used to get notifications of changes in the status of a specific function of the
gateway. It is sent spontaneously by the gateway itself.
• GET: Command used to get the status of a specific function. It is sent by the client.
To know more about the Home Automation protocol, see the
Table 7. Indoor units signals
Name
On/Off
Operation Mode
Fan Speed
Vane Position
Temperature Setpoint (x10)
AC Ambient Temperature (x10)
Unit Error code
Error IU
NOTE
1
This index must be set accordingly to the Unit ID Index.
For outdoor units, the acNum value must be the same than the minimum indoor unit associated in
the CONFIGURATION section.
USER MANUAL Version 1.0.1
Possible values
ON/OFF
HEAT/COOL/FAN/DRY/AUTO
1/2/3/4/5/AUTO
Stop/Swing
°C / °F
-35 .. 92.5ºC / -31 .. 198.5ºF
0-No Error, X-Error
OK/ERR
Midea commecial and VRF with KNX, Serial and IP support
Protocol specifications manual.
1
acNum Commands supported
SET/CHN/GET
SET/CHN/GET
SET/CHN/GET
SET/CHN/GET
See the note below
SET/CHN/GET
CHN/GET
CHN/GET
CHN/GET
