Midea commecial and VRF with KNX, Serial and IP support
Object name
Status_Cool mode
Control_Fan mode
Status_Fan mode
Control_Dry mode
Status_Dry mode
Control_Temperature setpoint
Status_Temperature setpoint
Control_Fan speed enumerated
Status_Fan speed enumerated
Control_Fan speed scaling
Status_Fan speed scaling
Control_Fan speed low
Status_Fan speed low
Control_Fan speed medium
Status_Fan speed medium
Control_Fan speed high
Status_Fan speed high
Control_Fan speed Man/Auto
Status_Fan speed Man/Auto
Control_VanesUD position swing
Status_VanesUD position swing
Status_AC ambient temperature
Control_KNX ambient temperature
Status_Unit error code
Control_Remote control lock
Status_Remote control lock
Control_Force operating mode
Status_Force operating mode
Status_Consumption Yesterday
Status_Consumption Today
Status_Consumption Total
Status_Consumption Yesterday Heat
Status_Consumption Today Heat
Status_Consumption Total Heat
Status_Consumption Yesterday Cool
Status_Consumption Today Cool
Status_Consumption Total Cool
NOTE
The default unit for the consumption signals is Wh, but you can set it in KWh instead. If so, the DPT
number changes from 13.010 to 13.013.
Page 28 of 34
Possible values
1-Cool mode active, 0-Cool mode not active
1-Set fan mode
1-Fan mode active, 0-Fan mode not active
1-Set dry mode
1-Dry mode active, 0-Dry mode not active
17 .. 30ºC / 62 .. 86ºF
17 .. 30ºC / 62 .. 86ºF
0-Low, 1-Medium, 2-High
0-Low, 1-Medium, 2-High
Thresholds (0.. 49%; 50 .. 82%; 83 .. 100%)
Thresholds (33%; 66%; 100%)
1-Set fan speed low
1-Speed low active, 0-Speed low not active
1-Set fan speed medium
1-Speed medium active, 0-Speed medium not active
1-Set fan speed high
1-Speed high active, 0-Speed high not active
0-Manual; 1-Auto
0-Manual; 1-Auto
0-Swing off; 1-Swing on
0-Swing off; 1-Swing on
0 .. 30ºC / 32 .. 86ºF
ºC / ºF
0-No Error, n-Error (0 .. 255)
0-Unlock, 1-Lock
0-Unlock, 1-Lock
0-No force, 1-Force
0-No force, 1-Force
n Wh / n kWh
n Wh / n kWh
n Wh / n kWh
n Wh / n kWh
n Wh / n kWh
n Wh / n kWh
n Wh / n kWh
n Wh / n kWh
n Wh / n kWh
Integration into KNX Systems
DPT
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
9.001/9.027-DPT_Value_Temp (2byte)
9.001/9.027-DPT_Value_Temp (2byte)
5.x (1byte)
5.x (1byte)
5.001-DPT_Scaling (1byte)
5.001-DPT_Scaling (1byte)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
9.001/9.027-DPT_Value_Temp (2byte)
9.001/9.027-DPT_Value_Temp (2byte)
8.x (2 byte)
1.002 DPT_Bool (1bit)
1.002 DPT_Bool (1bit)
1.002 DPT_Bool (1bit)
1.002 DPT_Bool (1bit)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
USER MANUAL Version 1.0.1
Flags
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
R, T
R, T
R, T
R, T
R, T
R, T
R, T
R, T
R, T
