Product Specific Applications

! WARNING
Personal Fall Arrest: Truss Boss Anchor may be used to support a MAXIMUM 1 Personal Fall Arrest
System (PFAS) for use in Fall Arrest applications. Structure must withstand loads applied in the
directions permitted by the system of at least 5,000 lbs. Maximum free fall is 6', or up to 12' if
used in combination with equipment explicitly certified for such use. Applicable D-ring: Dorsal.
Restraint: Truss Boss Anchor may be used in Restraint applications. Restraint systems prevent
workers from reaching the leading edge of a fall hazard. Always account for fully deployed length
of lanyard/SRL. Structure must withstand loads applied in the directions permitted by the system
of at least 1,000 lbs. No free fall is permitted. Restraint systems may only be used on surfaces
with slopes up to 4/12 (vertical/horizontal). Applicable D-rings: Dorsal, Chest, Side, Shoulder.
Work Positioning: Truss Boss Anchor may be used in Work Positioning applications. Work
Positioning systems allow a worker to be supported while in suspension and work freely with
both hands. Structure must withstand loads applied in the directions permitted by the system of
at least 3,000 lbs. Maximum allowable free fall is 2'. Applicable D-rings: Side.
(including all clothing, tools, and equipment) is 130-420 lbs.

Limitations

Fall Clearance: There must be sufficient
clearance below the anchorage connector
to arrest a fall before the user strikes the
ground or an obstruction. When
calculating fall clearance, account for a
MINIMUM 3' safety factor, deceleration
distance, user height, length of
lanyard/SRL, harness stretch, and all
other applicable factors.
Diagram shown is an example fall
clearance calculation ONLY.
Swing Falls: Prior to installation or use,
make considerations for eliminating or
minimizing all swing fall hazards.
Swing falls occur when the anchor is not
directly above the location where a fall
occurs. Always work as close to in line
with the anchor point as possible. Swing
falls significantly increase the likelihood
of serious injury or death in the event
of a fall.
Use of equipment in unintended applications may result in serious
injury or death. Maximum 1 attachment per connection point.
For all applications: worker weight capacity range
Fall clearance calculation shown based on standing
worker falling directly in-line with anchor point.
Always consider potential swing fall and other
hazards when calculating fall clearance.
*Eliminate Swing Fall whenever
possible! If Swing Fall exists,
always account for additional
fall clearance.
