6.1.1.1 Nominal width 1000, 1050,1200,1250,1350,1500 – Bracket II
All three stabilizers of the device must always rest on the upper edge of the gripping good (manhole)! (see
Fig. 3)
As soon as only one of the three stabilizers has a larger distance than 15 mm (between stabilizer lower edge
and gripping good upper edge), it is in no case allowed, to lifted the gripping good!
TIP: Lower the device to the ground and try again.
Otherwise it exists slipping danger of the gripping good!
Stabilizer
(Side arm
(support)
Stabilizer
lower edge
54000047 V1
19 / 28
Gripping good
upper edge
Gripping
good
(manhole)
Fig. 3
