General
3.2

Survey and construction

1 Lifting eye (with chain suspension) for for carrier
2 Coulisse
3 Suspension position for shaft cones
4 Guiding shaft
Side arm (support) with sticker for positioning direction
5
for shaft cones
54000047
6 Bracket II
7 Bracket III
8 Side arm (support)
9 Suspension position for manholes
V1
