Maintenance and care
STABILIZER (Side arm/support)
1
GUIDING SHAFT
Keep guiding shaft free of dirt.
Grease if necessary the upper and lower range of the guiding shaft (see
arrows).
The manufacturer of the device does not take over any adhesion for malfunctions, which are to due to
maintenance periods not taken place, rough contamination and maintenance lacking.
54000047
The distance (A) between stabilizer (1) and bracket
fulcrum (2) must be equal large with all three stabilizer.
Differently large distances are referring to bent stabilizer
(1).
•
A
2
Guiding shaft
V1
Correct bent stabilizer (1).
26 / 28
